RFL-XXXX-300-R

Laser by IPG Photonics
Download Datasheet
Request Quote

Note: Your Quotation Request will be directed to IPG Photonics.

The RFL-XXXX-300-R from IPG Photonics is a Laser with Wavelength 1.1 to 1.8 µm, Power 300 W, Output Power (CW) 300 W. More details for RFL-XXXX-300-R can be seen below.

Product Specifications

View similar products

Product Details

  • Part Number
    RFL-XXXX-300-R
  • Manufacturer
    IPG Photonics
  • Description
    Midpower Near IR Raman Fiber Lasers

General Parameters

  • Type
    Laser System
  • Configuration
    Laser Head with Control Unit (Integrated), OEM Laser Module
  • Application Industry
    Environmental, Scientific / Research, Medical
  • Application
    Remote Sensing, Contaminant Detection, Spectroscopy, Laser Surgery, Dermatology, Oncology, Ophthalmology, Test & Measurement, Laser pumping
  • Operation Mode
    CW Laser
  • Wavelength
    1.1 to 1.8 µm
  • Spectral Width :
    1 to 3 nm
  • Power
    300 W
  • Output Power (CW)
    300 W
  • Tunable
    No
  • Fiber Coupled
    Yes
  • Mode
    Single-Mode
  • Laser Color
    Infrared, Near-Infrared
  • Polarization Orientation
    Linear, Random
  • Gain Medium Type
    Solid State Laser
  • Power Consumption
    1500 W
  • Power Stability
    ±2%
  • RMS Noise Power
    2% RMS
  • Power Supply
    100 to 240 VAC

Physical Properties

  • Package
    19" Rack-Mount
  • Dimension
    448 x 500 x 177 mm, 448 x 580 x 133 mm
  • Weight
    25 Kg, 30 Kg

Environmental Conditions

  • Cooling Method
    Air-Cooled, Water-Cooled
