6018-M003

Laser by QPC Lasers
Download Datasheet
Request Quote

Note: Your Quotation Request will be directed to QPC Lasers.

The 6018-M003 from QPC Lasers is a Laser with Wavelength 1870 to 1880 nm, Power 5 W, Output Power (CW) 5 W, Operating Temperature 20 to 30 Degree C, Storage Temperature -20 to 70 Degree C. More details for 6018-M003 can be seen below.

Product Specifications

View similar products

Product Details

  • Part Number
    6018-M003
  • Manufacturer
    QPC Lasers
  • Description
    1875 nm, 5 W, 400 µm fiber-coupled module with Medica options

General Parameters

  • Type
    Laser Module
  • Configuration
    Laser Head with Control Unit (Separate)
  • Application Industry
    Medical
  • Application
    Nerve Stimulation, Surgery
  • Operation Mode
    CW Laser
  • Wavelength
    1870 to 1880 nm
  • Spectral Width :
    20 nm
  • Power
    5 W
  • Output Power (CW)
    5 W
  • Tunable
    No
  • Fiber Coupled
    Yes
  • Laser Color
    Infrared
  • Connectors
    HP-SMA905, DB15
  • Current
    45 to 55 A
  • Laser Class
    Class 4
  • Numerical Aperture
    0.22
  • Voltage
    1 to 1.2 V
  • RoHS
    Yes
  • Note
    E-O Conversion Efficiency: 10%

Physical Properties

  • Dimension
    88 x 40 x 36 mm
  • Fiber diameter
    400 µm

Environmental Conditions

  • Operating Temperature
    20 to 30 Degree C
  • Storage Temperature
    -20 to 70 Degree C
