RA650C3FX

Download Datasheet
Request Quote

Note: Your Quotation Request will be directed to Laserglow Technologies.

The RA650C3FX from Laserglow Technologies is a Laser with Wavelength 1063.2 nm, Power 50000 mW, Operating Temperature 10 to 35 Degree C, Storage Temperature -10 to 50 Degree C. More details for RA650C3FX can be seen below.

Product Specifications

View similar products

Product Details

  • Part Number
    RA650C3FX
  • Manufacturer
    Laserglow Technologies
  • Description
    1064 nm IR DPSS Laser System

General Parameters

  • Type
    Laser system
  • Configuration
    Laser Head with Control Unit (Separate)
  • Application Industry
    Scientific / Research, Communications
  • Application
    Test & Measurement, Optical Fiber Communication, Spectrum Analysis
  • Operation Mode
    CW Laser
  • Wavelength
    1063.2 nm
  • Wavelength Accuracy
    +/-1 nm
  • Power
    50000 mW
  • Technology
    DPSS Laser
  • Tunable
    No
  • Fiber Coupled
    Yes
  • Mode
    Multi-Mode
  • Laser Color
    Infrared
  • Transverse Mode
    Near TEM00
  • Beam Divergence :
    3.5 mrad
  • Gain Medium Type
    Solid State Laser
  • Laser Class
    Class IV
  • Warm up time
    10 Min.
  • Modulation Frequency
    30 kHz
  • Analog Modulation
    30 kHz
  • Power Stability
    3% RMS/4h
  • Pointing Stability :
    0.05 mrad
  • Power Supply
    85 to 264 V
  • Voltage
    0 to 5 VDC

Physical Properties

  • Laser Head Dimension
    426 x 150 x 130 mm
  • Laser Head Weight
    15 kg
  • Power Supply Dimension
    340 x 463 x 221 mm
  • Power Supply Weight
    18.5 Kg
  • Beam Diameter
    6 mm

Environmental Conditions

  • Operating Temperature
    10 to 35 Degree C
  • Storage Temperature
    -10 to 50 Degree C

Technical Documents
Click to view more product details on manufacturer's website
Request a Quote
