MNL 103-LD

Download Datasheet
Request Quote

Note: Your Quotation Request will be directed to LTB Lasertechnik Berlin.

The MNL 103-LD from LTB Lasertechnik Berlin is a Laser with Wavelength 337.1 nm, Power 30 kW, Output Power (Pulsed) 30 kW, Pulse Energy 80 to 90 µJ, Pulse Width 3 ns. More details for MNL 103-LD can be seen below.

Product Specifications

View similar products

Product Details

  • Part Number
    MNL 103-LD
  • Manufacturer
    LTB Lasertechnik Berlin
  • Description
    The MNL 100 nitrogen laser is representing the cutting edge in small compact UV lasers

General Parameters

  • Type
    Laser System
  • Configuration
    Laser Head with Control Unit (Integrated), OEM Laser Module
  • Ultrafast Laser
    Nanosecond Lasers
  • Application Industry
    Automotive / Industrial & Manufacturing, Environmental, Scientific / Research, Medical
  • Application
    Cutting, Drilling, Engraving, 3D Printing, Welding, Remote Sensing, Spectroscopy, Test & Measurement, Microscopy, Dermatology, Laser pumping
  • Operation Mode
    Pulsed Laser
  • Wavelength
    337.1 nm
  • Spectral Width :
    0.1 nm
  • Power
    30 kW
  • Output Power (Pulsed)
    30 kW
  • Pulse Energy :
    80 to 90 µJ
  • Pulse Energy
    80 to 90 µJ
  • Pulse Width
    3 ns
  • Repetition Rate
    1 to 30 Hz
  • Technology
    Gas Laser, Solid State Laser
  • Tunable
    Yes
  • Fiber Coupled
    No
  • Laser Color
    Ultraviolet
  • Beam Divergence :
    0.5 x 0.3 mrad
  • Gain Medium Type
    Gas Laser
  • Laser Cavity Material
    Nitrogen
  • Laser Gain Medium
    Molecular Laser
  • Current
    1.6 A
  • Laser Class
    Class 3B/IIIb
  • Warm up time
    20 s
  • Peak Power
    40 to 60 W
  • Interface
    RS-232
  • Voltage
    24 VDC
  • RoHS
    Yes
  • Note
    Focus Stability: 25 µm , Jitter: ± 2.5 ns, Peak Current: 2.4 A

Physical Properties

  • Laser Head Dimension
    321 x 95 x 95 mm
  • Laser Head Weight
    3.5 kg
  • Power Supply Dimension
    180 x 80 x 50 mm
  • Power Supply Weight
    0.6 kg
  • Beam Area
    Beam Dimension: 4 x 2.5 mm

Environmental Conditions

  • Cooling Method
    Air-Cooled
  • Relative Humidity
    85% (Non-Condensing)
  • Operating Temperature
    15 to 38 Degree C
  • Storage Temperature
    -10 to 60 Degree C
