axiom LE

Download Datasheet
Request Quote

Note: Your Quotation Request will be directed to Novanta Photonics.

The axiom LE from Novanta Photonics is a Laser with Wavelength 532 nm, Power 4 to 12 W, Operating Temperature 20 to 29 Degree C. More details for axiom LE can be seen below.

Product Specifications

View similar products

Product Details

  • Part Number
    axiom LE
  • Manufacturer
    Novanta Photonics

General Parameters

  • Type
    Laser System
  • Configuration
    Laser Head with Control Unit (Separate), OEM Laser Module
  • Application Industry
    Automotive / Industrial & Manufacturing
  • Application
    Machine Vision
  • Operation Mode
    CW Laser
  • Wavelength
    532 nm
  • Power
    4 to 12 W
  • Tunable
    No
  • Fiber Coupled
    No
  • Laser Color
    Green
  • Polarization
    Horizontal
  • Polarization ratio :
    >100:1
  • Transverse Mode
    TEM00
  • Beam Divergence :
    <0.4 mrad
  • Beam Quality Factor (M2) :
    <1.1
  • Laser Class
    Class IV
  • Warm up time
    <10 min
  • Power Stability
    <0.25%
  • Pointing Stability :
    10 µrad / Degree C
  • RMS Noise Power
    <0.25%
  • Warranty
    2 Years

Physical Properties

  • Package
    Benchtop
  • Laser Head Weight
    3.9 kg
  • Weight
    3.9 kg
  • Beam Diameter
    2.25 ± 0.25 mm

Environmental Conditions

  • Cooling Method
    Water-Cooled
  • Operating Temperature
    20 to 29 Degree C
