VA-I-50-457

Laser by Optotronics
Request Quote

Note: Your Quotation Request will be directed to Optotronics.

The VA-I-50-457 from Optotronics is a Laser with Wavelength 457 nm, Power 50 mW, Output Power (CW) 50 mW, Operating Temperature 18 to 30 Degree C. More details for VA-I-50-457 can be seen below.

Product Specifications

View similar products

Product Details

  • Part Number
    VA-I-50-457
  • Manufacturer
    Optotronics
  • Description
    457nm DPSS blue laser systems

General Parameters

  • Type
    Laser System
  • Configuration
    Laser Head with Control Unit (Separate)
  • Application Industry
    Scientific / Research, Entertainment, Automotive / Industrial & Manufacturing, Medical
  • Application
    DNA Sequencing, Spectroscopy, Interferometry, Holography, Fluorescence, Inspection & Measurement, Imaging, Microscopy, Diagnosis, Spectrum Analysis
  • Operation Mode
    CW Laser
  • Wavelength
    457 nm
  • Spectral Width :
    0.1 nm
  • Power
    50 mW
  • Output Power (CW)
    50 mW
  • Technology
    DPSS Laser
  • Tunable
    No
  • Fiber Coupled
    No
  • Laser Color
    Blue
  • Polarization Orientation
    Linear
  • Transverse Mode
    TEM00
  • Beam Divergence :
    1.2 mrad
  • Gain Medium Type
    Solid State Laser
  • Beam Shape
    Round
  • Warm up time
    15 Minutes
  • Modulation Frequency
    30 KHz
  • Power Stability
    5% RMS
  • Power Supply
    110-120V 60hz (15A), 220-240V 50hz (10A)
  • Note
    Expected Lifetime: 10000 h

Physical Properties

  • Laser Head Dimension
    180 x 62 x 62 mm
  • Beam Diameter
    1.2 mm

Environmental Conditions

  • Operating Temperature
    18 to 30 Degree C
