TruDiode 151

Laser by TRUMPF

Note: Your Quotation Request will be directed to TRUMPF.

The TruDiode 151 from TRUMPF is a Diode Laser that operates at a wavelength of 920 nm - 970 nm. It delivers an output power of 150 W and has a power constancy of ± 1%. This laser has a beam quality factor (M2) of 8 mm.mrad and minimum laser light cable diameter of 150 µm. It has a numerical aperture of 0.12 and uses TruControl software. This laser is available in a compact package that measures 483 (W) mm x 495 (H) mm x 513 (D) mm and is ideal for plastic welding & soldering applications.

Product Specifications

View similar products

Product Details

  • Part Number
    TruDiode 151
  • Manufacturer
    TRUMPF
  • Description
    920 nm - 970 nm, Diode Laser for Plastic Welding Applications

General Parameters

  • Type
    Laser System
  • Configuration
    Laser Head with Control Unit (Integrated)
  • Application Industry
    Automotive / Industrial & Manufacturing
  • Application
    Welding, Selective Soldering
  • Operation Mode
    CW Laser
  • Wavelength
    920, 970 nm
  • Power
    3 to 150 W
  • Output Power (CW)
    3 to 150 W
  • Tunable
    No
  • Fiber Coupled
    No
  • Laser Color
    Infrared
  • Beam Divergence :
    8 mrad
  • Gain Medium Type
    Solid State Laser

Physical Properties

  • Dimension
    483 x 495 x 513 mm
  • Fiber diameter
    150 µm
  • Fiber length
    6 to 15 m

Environmental Conditions

  • Operating Temperature
    5 to 40 Degree C
