CW-300MM

Download Datasheet
Request Quote

Note: Your Quotation Request will be directed to VONJAN Technology.

The CW-300MM from VONJAN Technology is a Laser with Wavelength 1080 nm, Power 300 W, Operating Temperature 0 to 40 Degree C, Storage Temperature -10 to 60 Degree C. More details for CW-300MM can be seen below.

Product Specifications

View similar products

Product Details

  • Part Number
    CW-300MM
  • Manufacturer
    VONJAN Technology
  • Description
    1080 nm Near-Infrared 300 W CW Laser

General Parameters

  • Type
    Laser System
  • Configuration
    Laser Head with Control Unit (Separate)
  • Application Industry
    Automotive
  • Application
    Cutting, Decoating, Welding, Cleaning
  • Operation Mode
    CW Laser
  • Wavelength
    1080 nm
  • Power
    300 W
  • Tunable
    No
  • Fiber Coupled
    Yes
  • Mode
    Multi-Mode
  • Laser Color
    Near-Infrared
  • Polarization Orientation
    Random
  • Laser Class
    Class 4
  • Modulation Frequency
    1 to 20 kHz
  • Power Consumption
    1200 W
  • Voltage
    48 VDC
  • Note
    Beam Parameter Product: 1 mm x mrad, Power Tuning Range: 10 to 100%, Power instability: 1%

Physical Properties

  • Package
    Benchtop
  • Dimension
    620 x 450 x 177 mm (W x D x H)
  • Weight
    24.8 kg
  • Fiber diameter
    50 µm
  • Fiber length
    5 m

Environmental Conditions

  • Cooling Method
    Air Cooled
  • Operating Temperature
    0 to 40 Degree C
  • Storage Temperature
    -10 to 60 Degree C
