DPGL-0.4S

Laser by World Star Tech
Download Datasheet
Request Quote

Note: Your Quotation Request will be directed to World Star Tech.

The DPGL-0.4S from World Star Tech is a Laser with Wavelength 532 nm, Power 4 mW, Output Power (CW) 4 mW, Operating Temperature 10 to 40 Degree C, Storage Temperature -40 to 80 Degree C. More details for DPGL-0.4S can be seen below.

Product Specifications

View similar products

Product Details

  • Part Number
    DPGL-0.4S
  • Manufacturer
    World Star Tech
  • Description
    DPGL Series Green Laser Module

General Parameters

  • Type
    Laser Module
  • Configuration
    Laser Head
  • Application Industry
    Scientific / Research, Automotive / Industrial & Manufacturing
  • Application
    Test & Measurement, Inspection & Measurement, Alignment
  • Operation Mode
    CW Laser
  • Wavelength
    532 nm
  • Power
    4 mW
  • Output Power (CW)
    4 mW
  • Tunable
    No
  • Fiber Coupled
    No
  • Laser Color
    Green
  • Transverse Mode
    TEM00
  • Beam Divergence :
    1 mrad
  • Beam Shape
    Circular
  • Current
    150 mA
  • Laser Class
    Class 1
  • Voltage
    3.3 VDC
  • RoHS
    Yes
  • Note
    Cable: 200mm

Physical Properties

  • Dimension
    15 x 69 mm(D x L)
  • Beam Diameter
    1.2mm

Environmental Conditions

  • Operating Temperature
    10 to 40 Degree C
  • Storage Temperature
    -40 to 80 Degree C
