C460UT190-Sxxxx| UT190 G1™

LED by Cree LED
477 more products from this company
Download Datasheet
Request Quote

Note: Your Quotation Request will be directed to Cree LED.

The C460UT190-Sxxxx| UT190 G1™ from Cree LED is a LED with Forward Voltage 2.7 to 3.1 V, Forward Current 30 mA, Reverse Current 2 µA, Wavelength 460 nm, Power 8 mW. More details for C460UT190-Sxxxx| UT190 G1™ can be seen below.

Product Specifications

View similar products

Product Details

  • Part Number
    C460UT190-Sxxxx| UT190 G1™
  • Manufacturer
    Cree LED
  • Description
    460 nm Blue Chip LEDs with 30 mA Forward current

General Parameters

  • Colors
    Blue
  • Configuration
    Chip, Die
  • Electrostatic Discharge(ESD)
    Class 2
  • Peak Pulse Current
    100 mA
  • RoHS
    Yes
  • Series
    Chips UT
  • Type
    CHIP LED
  • Forward Voltage
    2.7 to 3.1 V
  • Forward Current
    30 mA
  • Reverse Current
    2 µA
  • Wavelength
    460 nm
  • Power
    8 mW
  • Reverse Voltage
    5 V

Physical Properties

  • Package
    Chip
  • Package Type
    Chip

Environmental Conditions

  • Junction Temperature
    125 Degree C
  • Operating Temperature
    -40 to 100 Degree C
  • Storage Temperature
    -40 to 120 Degree C

Applications

  • Application
    Mobile Phone Keypad Backlights, Audio Product Display Lighting, Indicators (Automotive, Consumer Products, Wearable Devices, White Goods)
