The SMBB760D-3100S-I from Marubeni is an AlGaInP LED that operates at a peak wavelength of 760 nm. It delivers an output power of 1700 mW & 4000 mW and has a half-width of 25 nm. It has a rise time of 50 ns and fall time of 100 ns. This LED has 3 chips with a chip dimension of 1000 μm x 1000 μm. It has a forward voltage of 6 V & 7.5 V, reverse current of up to 10 μA, and dissipates a power of 6000 mW. It has a silicone resin lens and silver plated on copper lead frame die. This LED is available in a PA9T resin package that measures 5.2 mm x 5 mm x 1 mm.
