Lms43LED-4M

28 more products from this company
Download Datasheet
Request Quote

Note: Your Quotation Request will be directed to LED Microsensor NT.

The Lms43LED-4M from LED Microsensor NT is a LED with Current 1000 mA, Forward Voltage 0.3 to 0.7 V, Forward Current 10-1000 mA, Wavelength 4100 to 4300 nm, Power 50 to 100 µW. More details for Lms43LED-4M can be seen below.

Product Specifications

View similar products

Product Details

  • Part Number
    Lms43LED-4M
  • Manufacturer
    LED Microsensor NT
  • Description
    Mid-Infrared (MIR) Standard 4-element one-wavelength LED array

General Parameters

  • Colors
    Mid-Infrared (MIR)
  • Configuration
    Array
  • Peak Pulse Current
    8 A (Pulse)
  • Current
    1000 mA
  • Forward Voltage
    0.3 to 0.7 V
  • Forward Current
    10-1000 mA
  • Wavelength
    4100 to 4300 nm
  • Power
    50 to 100 µW
  • Note
    Window Material: refer to datasheet, pulse duration: qCW: 1 ms, Pulse: 20 us, Duty cycle: qCW: 50%, Pulse: 1%

Physical Properties

  • Package
    TO-18, TO-5
  • Package Type
    Through-Hole

Environmental Conditions

  • Operating Temperature
    -60 to 90 Degree C
  • Storage Temperature
    -60 to 90 Degree C

Technical Documents
