YAG-100AH

Photodiode by Excelitas Technologies
Download Datasheet
Request Quote

Note: Your Quotation Request will be directed to Excelitas Technologies.

The YAG-100AH from Excelitas Technologies is a Photodiode with Wavelength Range 400 to 1150 nm, Bandwidth 30 MHz, Capacitance 2.5 pF, Dark Current 11 to 20 nA, Responsivity/Photosensitivity 0.44 to 0.70 A/W. More details for YAG-100AH can be seen below.

Product Specifications

View similar products

Product Details

  • Part Number
    YAG-100AH
  • Manufacturer
    Excelitas Technologies
  • Description
    Silicon PIN Photodiode from 400 to 1150 nm

Applications

  • Application
    Instrumentation, Laser range finding, Laser warning receivers, Missile guidance systems

General Parameters

  • Breakdown Voltage
    200 V
  • Configuration
    Single
  • Module
    No
  • Noise equivalent power(NEP) :
    0.08 pW/vHz
  • Package
    TO-5
  • Package Type
    TO-Can
  • Photodetector Type
    PIN
  • Operation Mode
    Photoconductive
  • Wavelength Range
    400 to 1150 nm
  • Photodiode Material
    Silicon
  • RoHs
    Yes
  • Supply Voltage
    0 to 180 V
  • Bandwidth
    30 MHz
  • Capacitance
    2.5 pF
  • Dark Current
    11 to 20 nA
  • Responsivity/Photosensitivity
    0.44 to 0.70 A/W
  • Rise Time
    12 ns

Physical Properties

  • Active Area
    5.1 mm

Temperature

  • Operating Temperature
    -55 to 125 Degree C
  • Storage Temperature
    -55 to 125 Degree C
