1G-SFP-SX

Fiber Optic Transceiver by 3Coptics

Note: Your Quotation Request will be directed to 3Coptics.

The 1G-SFP-SX from 3Coptics is a Fiber Optic Transceiver with Data Rate 1 Gb/s, Wavelength 850 nm (VCSEL), Distance/Reach 500 m (Reach), Output Power -9.5 to -3 dBm, Receiver Sensitivity -18 dBm. More details for 1G-SFP-SX can be seen below.

Product Specifications

View similar products

Product Details

  • Part Number
    1G-SFP-SX
  • Manufacturer
    3Coptics
  • Description
    850 nm VCSEL Transceiver with -9.5 to -3 dBm Power

General Parameters

  • Data Rate
    1 Gb/s
  • Wavelength
    850 nm (VCSEL)
  • Distance/Reach
    500 m (Reach)
  • Output Power
    -9.5 to -3 dBm
  • Form Factor
    SFP
  • Receiver Sensitivity
    -18 dBm
  • Tx Power
    -9.5 to -3 dBm

Temperature

  • Operating Temperature
    0 to 70 Degree C
