TXC3XGJL2x000x0G

Fiber Optic Transceiver by Oplink Communications

Note: Your Quotation Request will be directed to Oplink Communications.

The TXC3XGJL2x000x0G from Oplink Communications is a Fiber Optic Transceiver that operates at a coarse wavelength division multiplexing (CWDM) wavelength. It is designed for multiple standard rates with a data rate of 10 Gbps and reach (distance) of 80 Km. This fiber optic transceiver is compatible with LC connectors and supports single-mode fiber. It has a form factor of XFP (10 gigabit small form-factor pluggable) and is ideal for telecommunication network applications.

Product Specifications

View similar products

Product Details

  • Part Number
    TXC3XGJL2x000x0G
  • Manufacturer
    Oplink Communications
  • Description
    Multi Rate Fiber Optic Transceiver for Network Applications

General Parameters

  • Data Rate
    10 Gb/s
  • Distance/Reach
    80 km
  • Fiber Modes
    Single Mode
  • Form Factor
    XFP
  • RoHs
    Yes
  • Note
    Spectral width: 1 nm, Extinctions ratio: 8.2 dB, Rise/Fall Time: 24 ps, Input Voltage: 0 V, Differential Input Voltage: (Rx): 120 to 820 mV, Differential Output Voltage: (Rx): 340 to 850 mV

Temperature

  • Operating Temperature
    -40 to 85 Degree C
  • Storage Temperature
    -40 to 85 Degree C
