UVL 355-15

Laser by AMTEC
Download Datasheet
Request Quote

Note: Your Quotation Request will be directed to AMTEC.

The UVL 355-15 from AMTEC is a Laser with Wavelength 355 nm, Power 15 W, Pulse Width <25 ns, Repetition Rate 0 to 500 kHz, Operating Temperature 18 to 35 Degree C. More details for UVL 355-15 can be seen below.

Product Specifications

View similar products

Product Details

  • Part Number
    UVL 355-15
  • Manufacturer
    AMTEC
  • Description
    355 nm UV Laser system with 15 W Power

General Parameters

  • Type
    Laser System
  • Configuration
    Laser Head with Control Unit (Integrated)
  • Ultrafast Laser
    Nanosecond Lasers
  • Application Industry
    Automotive / Industrial & Manufacturing, Scientific Research
  • Application
    Marking, LTPS Display annealing, Micro-machining, PCB Drilling and cutting, Silicone Wafer scribing, Si-Ablation, Texturing
  • Operation Mode
    Pulsed Laser
  • Wavelength
    355 nm
  • Power
    15 W
  • Pulse Width
    <25 ns
  • Repetition Rate
    0 to 500 kHz
  • Pulse to Pulse Stability
    <2% RMS
  • Tunable
    No
  • Fiber Coupled
    No
  • Laser Color
    Ultraviolet
  • Polarization
    Vertical
  • Polarization ratio :
    100:1
  • Transverse Mode
    TEM00
  • Beam Divergence :
    <0.6 mrad
  • Beam Shape
    Circular
  • Energy Stability
    <3 to 5% RMS
  • Power Consumption
    300 W
  • Pointing Stability :
    <±10 µrad/Degree C
  • Power Supply
    110 to 220 VAC, 50 to 60 Hz

Physical Properties

  • Dimension
    635 x 153 x 115 mm (L x W x H)
  • Weight
    12.7 kg
  • Beam Diameter
    1 mm

Environmental Conditions

  • Cooling Method
    Water Cooled
  • Relative Humidity
    8 to 95%
  • Operating Temperature
    18 to 35 Degree C
  • Storage Temperature
    -20 to 50 Degree C
