DE2020

Download Datasheet
Request Quote

Note: Your Quotation Request will be directed to IMRA America, Inc.

The DE2020 from IMRA America, Inc is a Laser with Wavelength 1045 nm, Power 20 W, Output Power (Pulsed) 20 W, Pulse Energy 20 µJ, Pulse Width 350 fs. More details for DE2020 can be seen below.

Product Specifications

View similar products

Product Details

  • Part Number
    DE2020
  • Manufacturer
    IMRA America, Inc

General Parameters

  • Type
    Laser System
  • Configuration
    Laser Head with Control Unit (Integrated)
  • Ultrafast Laser
    Femtosecond Lasers
  • Application Industry
    Scientific / Research, Medical, Automotive / Industrial & Manufacturing
  • Operation Mode
    Pulsed Laser
  • Wavelength
    1045 nm
  • Wavelength Accuracy
    ± 5 nm
  • Power
    20 W
  • Output Power (Pulsed)
    20 W
  • Pulse Energy :
    20 µJ
  • Pulse Energy
    20 µJ
  • Pulse Width
    350 fs
  • Repetition Rate
    1000 kHz
  • Technology
    Solid State Laser
  • Tunable
    No
  • Fiber Coupled
    Yes
  • Laser Color
    Infrared
  • Polarization
    Horizontal
  • Gain Medium Type
    Solid State Laser
  • Laser Gain Medium
    Ytterbium Laser
  • Warm up time
    60 minutes
  • Power Consumption
    1200 W
  • Power Stability
    1% rms
  • Voltage
    100 to 240 VAC
  • Note
    Output Aperture Height: 55.4 mm, Head Heat Dissipation: 100 W

Physical Properties

  • Laser Head Dimension
    666 x 520 x 165 mm³
  • Laser Head Weight
    45 kg
  • Power Supply Dimension
    433 x 483 x 222 mm³
  • Power Supply Weight
    30 kg
  • Fiber length
    3 m

Environmental Conditions

  • Cooling Method
    Air-Cooled
  • Operating Temperature
    20 to 30 Degree C
  • Storage Temperature
    0 to 50 Degree C
