| New Photonics Products this Week |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| Single-Mode UV Laser Diode from 370 nm to 380 nm | |
Laser Diode
from Nichia Corporation
|
| The NDU4116 from Nichia Corporation is a UV Laser Diode that operates at a wavelength of 370 - 380 nm with a slope efficiency of 1.2 W/A. It delivers an optical output power of 70 mW and a beam pointing accuracy of ±3°. This laser diode has a parallel beam divergence of 9° and perpendicular beam divergence of 22.5°. It has a threshold current of 50 mA and PD reverse voltage of up to 5 V. This single-mode laser diode is available in a Floating Mounted Can Package. |
| |
Download Datasheet
Product Details | |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| Mid-Infrared (MIR) Photodiode from 2.8 to 4.9 µm | |
Photodiode
from LED Microsensor NT
|
| The Lms49PD-05 Series from LED Microsensor NT is a Photodiode that offers a fast response speed for Mid-IR applications. It has a sensitive area of 0.5 mm with a maximum sensitivity range of 3.55 - 4.50 μm. This photodiode has a dark current of 17 mA and photosensitivity of 1 A/W. The cut-off wavelength (at 10% level) for this photodiode varies from 4.9 to 5.0 μm. It is available in both TO-18 and TO-5 packages with a wide variety of choices. |
| |
Download Datasheet
Product Details | |
|
|
|
|
|
|
