| New Photonics Products this Week |
|
|
| Optical Spectrum Analyzer from 350 - 1200 nm for Light Measurement Applications | |
Optical Spectrum Analyzer
from Yokogawa Test & Measurement Corporation
|
| The AQ6373E from Yokogawa Test & Measurement Corporation is an Optical Spectrum Analyzer (OSA) with a wavelength of 350 nm - 1200 nm. It has a full span range of 0.5 nm - 850 nm and is ideal for characterization of laser sources, characterization of supercontinuum light sources, visible LED test, pulsed light measurement, gas detection & concentration measurement applications. |
| |
Download Datasheet
Product Details | |
|
|
|
|
|
|
|
|
| 343 nm UV Grade Fused Silica Optical Mirror | |
Optical Mirror
from OPTOMAN
|
| The PP-UVFS-25.4-6.35-LLM267EL from OPTOMAN is an Ultrafast Laser Mirror that operates at a wavelength of 343 nm. It has a diameter of 25.4 mm, thickness of 6.35 mm, and chip size of less than 0.2 mm. This UV-grade fused silica (UVFS) optical mirror has a minimum clear aperture of 90% and surface quality of 10-5 S-D (scratch-dig). It has a maximum surface flatness of 1/10th of wavelength (at 633 nm) and parallelism of 10 arcsec. |
| |
Download Datasheet
Product Details | |
|
|
|
|
|
|
|
|
|
|
|
|
|
| Optical Delay Line for Phased Array Antenna System Appliactions | |
Optical Delay Line
from Optical Zonu
|
| The SWITCHED RF DELAY SYSTEM from Optical Zonu is an Optical Delay Line that has a frequency of 10 kHz - 50 GHz. It has a switching time of 6 msec - 10 msec and delay resolution of 1 nsec. This optical delay line has switched delay of 212 (4096) and is ideal for radar system calibration, wireless system simulation & phased array antenna systems applications. |
| |
Download Datasheet
Product Details | |
|
|
|
| 1260 nm - 1650 nm, Optical Delay Line for Network Testing Applications | |
Optical Delay Line
from AFW Technologies
|
| The SM1-22-B-50-BX1 from AFW Technologies is an Optical Delay Line that operates at a wavelength of 1260 nm - 1650 nm. It has an insertion loss of 0.3 dB/km - 0.5 dB/km and supports G.652.D single mode fiber with a length of 50 m. This ODL is compatible with FC/UPC fiber connectors and is ideal for optical network testing & analysis, fiber laser & time delay applications. |
| |
Download Datasheet
Product Details | |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| Handheld Refractometer for Food Processing Industry Applications | |
Refractometer
from PCE Instruments
|
| The PCE-5890 from PCE Instruments is a Handheld Refractometer that has a measuring range of 58% - 90% (Brix), 12% - 27% (water content), and 35 degrees Baumé - 43 degrees Baumé (Bé°). It has a resolution of ± 0.5 % and an accuracy of ± 0.5%. This refractometer is ideal for use in beekeeping, honey production & food processing industry applications. |
| |
Download Datasheet
Product Details | |
|
|
|
|
|
|
|
|
| 335 nm - 2500 nm, Reflectometer for Field Measurement Applications | |
Reflectometer
from Surface Optics
|
| The 410-SOLAR-i from Surface Optics is a Reflectometer with spectral bands of 335 nm - 380 nm, 400 nm - 540 nm, 480 nm - 600 nm, 590 nm - 720 nm, 700 nm - 1100 nm, 1000 nm - 1700 nm, and 1700 nm - 2500 nm. It has a beam spot size of 0.5" and an angle of incidence of 20 deg. This reflectometer is ideal for field measurements, lab measurements, and LiDAR applications. |
| |
Download Datasheet
Product Details | |
|
|
|
| 1310 nm Michelson Interferometer for Fiber Sensing Systems | |
Interferometer
from Paulsson
|
| The MFI-13-50 from Paulsson is a Michelson Interferometer with that operates at a wavelength of 1310 nm. It delivers an optical power of 250 mW and has a modulator constant of 2 rad/V. This interferometer has a delay coil with a delay length range of 0.5 m - 1000 m and is ideal for precision test, measurement instrumentation & fiber sensing system applications. |
| |
Download Datasheet
Product Details | |
|
|
|
| 55 nm - 600 nm, Vacuum Ultraviolet Monochromator | |
Monochromator
from Resonance
|
| The VM92 from Resonance is a Vacuum Ultraviolet Monochromator that operates at a wavelength of 55 nm - 600 nm. It has a wavelength-accuracy of ± 0.3 nm and wavelength-reproducibility of ± 0.2 nm. This monochromator has resolution of 1 nm (with 150 µm slit) and grating density of 1800 grooves/mm. It has a dispersion of 5.5 nm/mm and slit width of 25 µm - 4000 µm. This monochromator has a quantum efficiency of over 15% and ultimate vacuum of -10-6 torr. |
| |
Download Datasheet
Product Details | |
|
|
|
| 190 nm - 2600 nm, Double Monochromator for Light Collection Applications | |
Monochromator
from Wavelight Technologies
|
| The WM400 from Wavelight Technologies is a Double Monochromator that operates at a wavelength of 190 nm - 2600 nm. It is a has a wavelength accuracy of ± 0.15 nm, ± 0.25 nm & ± 0.5 nm and repeatability of ± 0.05 nm, ± 0.1 nm & ± 0.2 nm. This monochromator has a wavelength step size of 0.01 nm, 0.02 nm & 0.04 nm and is ideal for applications such as light collection from samples. |
| |
Download Datasheet
Product Details | |
|
|
|
|
|
|
|
|
| 360 nm - 830 nm, Spectrometer for Chromaticity Measurement Applications | |
Spectrometer
from Photometric Solutions International
|
| The SP-4C from Photometric Solutions International is a Spectrometer that has a spectral range of 360 nm - 830 nm. It has a wavelength accuracy of up to 0.3 nm and wavelength repeatability of 0.02 nm. This spectrometer has an integration time of 0.01 ms - 65535 ms and stray light below 0.1%. It includes an 8-position filter wheel and is ideal for real-time chromaticity measurement applications. |
| |
Download Datasheet
Product Details | |
|
|
|
| 457/532/633 nm Spectrometer for Raman Spectroscopy Applications | |
Spectrometer
from NANOBASE
|
| The AUTORAM-C Series from NANOBASE is a Spectrometer with a wavelength of 457 nm, 532 nm, and 633 nm. It has a spectral range of 50 cm-1 - 3400 cm-1 (532 nm) and spectral resolution of 5.2 cm-1, 1.7 cm-1, 2.7 cm-1 & 0.9 cm-1. This spectrometer is ideal for material science, life science, pharmaceuticals, cosmetics, Raman spectroscopy & semiconductor application |
| |
Download Datasheet
Product Details | |
|
