| New Photonics Products this Week |
|
|
| 1080 nm CW Fiber Laser for 3D Printing & Scientific Research Applications | |
Laser
from Raycus
|
| The RFL-C3000S from Raycus is a CW Fiber Laser that operates at a central wavelength of 1080 nm. It delivers an average output power of 3000 W and has a wavelength accuracy of ± 5 nm. This red laser has a maximum modulation frequency of 1 Hz - 5000 Hz and beam quality factor (M2) of 1.5 mm x mrad – 2 mm x mrad. It is ideal for welding, cutting, cladding, scientific research, and 3D printing applications. |
| |
Download Datasheet
Product Details | |
|
|
|
| 213 nm Deep-Ultraviolet Laser for UV Raman Spectroscopy Applications | |
Laser
from OXIDE Corporation
|
| The Frequad-M from OXIDE Corporation is a CW DUV Laser that operates at a wavelength of 213 nm. It delivers an output power of 10 mW and has a linewidth of up to 0.005 pm. This single-frequency wavelength conversion laser has a TEM00 beam spatial mode and exhibits vertical and linear polarizations. It is ideal for semiconductor inspection, UV Raman spectroscopy, and FBG writing applications. |
| |
Download Datasheet
Product Details | |
|
|
|
| 1050 nm - 1070 nm, MOPA Pulsed Fiber Laser for Marking Applications | |
Laser
from Han's Laser Technology Industry Group
|
| The HFM-50H-1.0-CI-R from Han's Laser Technology Industry Group is a MOPA Pulsed Fiber Laser that operates at a wavelength of 1050 nm - 1070 nm. It delivers an average output power of 50 W and has a maximum single pulse energy of 1 mJ. This laser has 8 optional pulses with a pulse width of 4 ns - 200 ns. It is ideal for surface marking, sheet metal drilling and product QR code tracing applications. |
| |
Download Datasheet
Product Details | |
|
|
|
| 550 nm - 750 nm, Continuous Wave Tunable Dye Ring Laser | |
Laser
from Sirah Lasertechnik
|
| The Matisse 2 DX from Sirah Lasertechnik is a CW Dye Ring Laser that operates at a wavelength of 550 nm - 750 nm. It delivers an output power of up to 5.5 W and has a linewidth of less than 100 kHz rms/100 msec & 70 kHz rms/100 µsec. This horizontally polarized tunable laser produces a beam of radius 0.6 mm - 0.7 mm and has a beam divergence of less than 1.2 mrad (half-angle). |
| |
Download Datasheet
Product Details | |
|
|
|
| 904 nm AlGaInP MQW Infrared Laser Diode | |
Laser Diode
from US-Lasers, Inc.
|
| The HM904-5 from US-Lasers, Inc. is an AlGaInP IR Laser Diode that operates at a wavelength of 904 nm. It delivers a cw output power of 5 mW and has a slope efficiency of 0.5 mW/mA. This single-mode multi-quantum well LD has a beam divergence of 10 degrees (horizontal far-field) and 31 degrees (vertical far-field). It has a rise time of 1 ns, fall time of 2 ns, and reverse voltage of 2 V. This OEM LD has an astigmatism of 11 µm and an MTTF of 3000 - 5000 hrs. |
| |
Download Datasheet
Product Details | |
|
|
|
| 975 nm CW Multimode Laser Diode for Defense & Medical Applications | |
Laser Diode
from Sheaumann Laser
|
| The M5-975-0500-0 from Sheaumann Laser is a Laser Diode that operates at a wavelength of 975 nm. It delivers a cw output power of 500 mW and has a slope efficiency of 0.9 W/A. This multi-mode laser diode has a beam divergence of 30 degrees (vertical far-field) & 8 degrees (horizontal far-field) at FWHM. It is ideal for Raman spectroscopy, laser therapy, laser pumping, and defense applications. |
| |
Download Datasheet
Product Details | |
|
|
|
|
|
|
|
|
|
|
|
|
|
| 50.8 mm Dia, VUV Optical Bandpass Filter | |
Optical Filter
from eSource Optics
|
| The 50161FNB from eSource Optics is a Vacuum UV (VUV) optical bandpass filter that allows transmission at a peak wavelength of 161 nm. It has a bandwidth (FWHM) of 20 nm and wavelength tolerance of ± 2.5 nm. This optical filter has a minimum optical peak transmission of 12% and blocks approximately 10-3 UV through FIR. The edge chamfer of this optical filter measures nearly 0.5 mm x 45 degrees and has a clear aperture of 80% (central). |
| |
Download Datasheet
Product Details | |
|
|
| Sponsored by EMC Directory | | |
|
|
|
|
|
|
|
|
|
|
|
|
| 1310/1550 nm Fixed Fiber Optic Attenuator for Telecommunication Applications | |
Fiber Optic Attenuator
from O/E LAND INC.
|
| The OAT-HF from O/E LAND INC. is a Fixed Fiber Optic Attenuator that operates at wavelengths of 1310 nm or 1550 nm. It has an attenuation of 1dB, 2dB, 3dB, 5dB, 10dB, 15dB, and 20dB. This in-line fiber optic attenuator has an accuracy of ±0.5, ±0.75, ±0.8, ±1, ±1.5 & ±2 and a return loss above 45. It is ideal for telecommunication, CATV system, local area network, and other optical testing applications. |
| |
Download Datasheet
Product Details | |
|
|
|
|
|
|
|
|
| 26 Megapixel sCMOS Camera for Life Science & Physical Science Applications | |
Scientific & Industrial Camera
from Excelitas PCO
|
| The pco.edge 26 CLHS from Excelitas PCO is 26 MP sCMOS camera that has a resolution of 5120 (H) x 5120 (V) pixels. It has a global shutter that delivers a maximum frame rate of 150 fps at full resolution. This monochrome camera has a maximum pixel rate of 4608 MPixel/s and peak quantum efficiency of 72 % (at 500 nm). It is ideal for life science and physical science applications. |
| |
Download Datasheet
Product Details | |
|
|
|
|
|
|
