| New Photonics Products this Week |
|
|
| 266 nm DPSS Laser for Lithography & Scatterometry Applications | |
Laser
from CryLaS GmbH
|
| The FQCW 266-25 from CryLaS GmbH is a Diode Pumped Solid State Laser that operates at a wavelength of 266 nm. It has a wavelength stability of ± 1 nm and delivers an output power of 25 mW. This continuous wave laser has a power stability of 2% RMS and is ideal for lithography, Raman spectroscopy, interferometry, fluorescence, photoluminescence, and scatterometry applications. |
| |
Download Datasheet
Product Details | |
|
|
|
|
|
|
|
|
| 1064 nm Diode Pumped Nd:YAG Laser for Engraving & Marking Applications | |
Laser
from RMI Laser, LLC
|
| The UM-2 from RMI Laser is a Diode Pumped Nd:YAG Laser that operates at a wavelength of 1064 nm. It delivers a peak output power of up to 30 kW & 1 W (at 5 kHz) and has a pulse width of 8 ns (at 5 kHz). This laser has 2 F-theta lens options: 100 mm & 160 mm that produces a beam of diameter 2.5" x 2.5" (100 mm) and 5" x 5" (160 mm). It is ideal for laser-making & engraving applications. |
| |
Download Datasheet
Product Details | |
|
|
|
| 405 nm Single-Mode Laser Diode for Measurement Instruments | |
Laser Diode
from Nichia Corporation
|
| The NDV4316 from Nichia Corporation is a Violet Laser Diode that operates at a wavelength of 405 nm. It delivers a continuous-wave optical output power of 120 mW and has a slope efficiency of 1.4 W/A. This single-mode laser diode has a parallel beam divergence of 9 degrees and perpendicular beam divergence of 19.5 degrees. It is ideal for measurement instruments and household appliances. |
| |
Download Datasheet
Product Details | |
|
|
|
| 1650 nm DFB Laser Diode for Spectroscopy & Fiber Optic Sensor Applications | |
Laser Diode
from NTT Electronics Corporation
|
| The NLK1U5FAAA from NTT Electronics Corporation is a DFB Laser Diode that operates at a wavelength of 1650 nm. It delivers a minimum fiber output power of 15 mW and has a spectral linewidth of 2 MHz. This laser diode has a side mode suppression ratio above 35 dB and is ideal for Near-IR gas analysis, tunable diode laser absorption spectroscopy (TDLAS), and fiber optic sensor applications. |
| |
Download Datasheet
Product Details | |
|
|
|
| 50 Megapixel CMOS Image Sensor for Camera & Video Conference Applications | |
CMOS Image Sensor
from SK Hynix
|
| The AAA5021P from SK Hynix is a 50 Megapixel CMOS Image Sensor that has a resolution of 8192 (H) x 6144 (V) pixels. It has a 1/2.55" optical format that delivers a frame rate of 15 fps (at 8192 x 6144 px), 30 fps (at 4096 x 3072 px), and 240 fps (at 2048 x 1160 px). This CMOS image sensor is ideal for mobile phone cameras, digital still cameras, video conference, and PC camera applications. |
| |
Download Datasheet
Product Details | |
|
|
|
| 5.2 Megapixel CMOS Image Sensor for Biometric & Imaging Applications | |
CMOS Image Sensor
from Teledyne e2v
|
| The Lince5M from Teledyne e2v is a 5.2 Megapixel CMOS Image Sensor that has a resolution of 2560 (H) x 2048 (V) pixels. It has an electronic global shutter in a 1" optical format that delivers a frame rate of up to 250 fps. This image sensor has an active pixel size of 5 μm x 5 μm and is ideal for high-speed, generic inspection, low noise high dynamic range, biometric, and medical imaging applications. |
| |
Download Datasheet
Product Details | |
|
|
|
| 116 deg LED for Adaptive Driving Beam Lighting Applications | |
LED
from Samsung Semiconductors
|
| The PixCell LED from Samsung Semiconductors is an LED that has a luminance of 70 cd/mm2. It has a maximum luminance non-uniformity of 10% and viewing angle of 116 deg. This LED has 100 segments in a chip with a contrast ratio of 300:1 and radian surface of 0.35 mm2. It is ideal for low-beam, high-beam, and Adaptive Driving Beam (ADB) lighting for different headlamp applications. |
| |
Download Datasheet
Product Details | |
|
|
|
| 1300 nm Edge-Emitting LED for Data Transmission Systems | |
LED
from OSI Laser Diode, Inc.
|
| The LDT 362 from OSI Laser Diode, Inc. is an Edge-Emitting LED that operates at a center wavelength of 1300 nm. It has a spectral width of 80 nm and minimum output power of 40 µW & 80 µW (into a 50-micron core, multimode fiber at 150 mA). This multimode fiber LED has an optical rise/fall time of 4 ns and is ideal for data transmission systems, fiber optic modems & TFOCA systems applications. |
| |
Download Datasheet
Product Details | |
|
|
| Sponsored by EMC Directory | | |
|
|
| 800 nm Silicon Phototransistor for Industrial Equipment Applications | |
Phototransistor
from ROHM Semiconductor
|
| The SML-H10TB from ROHM Semiconductor is a Silicon Phototransistor that operates at a wavelength of 800 nm. It has a light current of 2 mA - 4 mA and dark current of up to 0.5 µA. This phototransistor has a CE voltage of 32 V, collector current of 30 mA, and an EC voltage of 5 V. It has a CE saturation voltage below 0.4 V and is ideal for home appliance & industrial equipment applications. |
| |
Download Datasheet
Product Details | |
|
|
|
| 400 nm - 495 nm, Color Glass Optical Filters for Bandpass Filter Applications | |
Optical Filter
from Optics and Allied Engineering Pvt. Ltd.
|
| The GG Series from Optics and Allied Engineering Pvt. Ltd. are Color Glass Optical Filters that allow transmission at a wavelength of 400 nm - 495 nm. They have a tolerance of ± 0.2mm, parallelism of up to 1 arc minutes, and flatness of 2λ (at 632.8nm). These Yellow glass optical filters have a clear aperture of greater than 90% and are ideal for long-pass and bandpass filter applications. |
| |
Download Datasheet
Product Details | |
|
|
|
| 1510 nm - 1590 nm, Fiber Optic Receiver for Spectrometry Applications | |
Fiber Optic Receiver
from LD-PD Inc
|
| The PDR-300M-A from LD-PD Inc is a Polarization Diversity Fiber Optic Receiver that operates at a wavelength of 1510 nm - 1590 nm. It has a detector responsivity of 0.95 A/W (at 1550 nm) and bandwidth of 300 MHz. This coherent fiber optic receiver has a trans-impedance gain of 30 KV/A and is ideal for optical fiber sensing, doppler wind LiDAR, OCT, laser ranging, and spectrometry applications. |
| |
Download Datasheet
Product Details | |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
