| New Photonics Products this Week |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| 343 nm UV Femtosecond Laser for Cutting & Drilling Applications | |
Laser
from MKS | Spectra-Physics
|
| The IceFyre FS UV50 from MKS Spectra-Physics is a UV Femtosecond Laser that operates at a wavelength of 343 nm. It has a wavelength accuracy of ±2 nm and delivers an output power of greater than 50 W (at 1 MHz & 1.25 MHz). This ultrashort laser is ideal for glass processing, OLED, Solar/PV scribing & drilling, 5G PCB cutting & drilling, and polymer cutting applications. |
| |
Download Datasheet
Product Details | |
|
|
|
|
|
|
|
|
| 940 nm CW Fiber-Coupled Laser Diode | |
Laser Diode
from LD4B
|
| The LD4B-940-FP-15 from LD4B is a Continuous Wave Laser Diode that operates at a wavelength of 940 nm. It delivers an output power of 20 mW and has a spectral width of 2 nm. This fiber-coupled laser diode has a slope efficiency of 0.4 mW/mA and polarization extinction ratio above 17. It requires a threshold current of 10 mA and DC supply voltage of 1.8 V. This laser diode supports SM05, SMP05 output fibers, and FC/UPC or FC/APC connectors. |
| |
Download Datasheet
Product Details | |
|
|
|
| 808 nm Quasi Continuous Wave Laser Diode for illumination Applications | |
Laser Diode
from Lumispot Tech
|
| The LM-8XX-Q3600-BG06H3-2 from Lumispot Tech is a Quasi Continuous Wave Laser Diode that operates at a center wavelength of 808 nm. It delivers an output power of 3600 W and has a wavelength tolerance of ±2 nm. This laser diode has a beam divergence of 36 degrees (fast axis) and 8 degrees (slow axis) at FWHM. It is ideal for illumination, detection, and research applications. |
| |
Download Datasheet
Product Details | |
|
|
|
|
|
|
|
|
| 3.2 Megapixel CMOS Image Sensor for Embedded Vision System Applications | |
CMOS Image Sensor
from Sony Semiconductor Solutions Corporation
|
| The IMX900-AQR from Sony Semiconductor Solutions Corporation is a 3.2 Megapixel CMOS Image Sensor that has an effective resolution of 2064 (H) x 1552 (V) pixels. It has a global shutter in a 1/3.1&rdquo optical format that deliver frame rates of 125.1 fps (8-bit), 117 fps (10-bit), and 72 fps (12-bit). This CMOS image sensor is ideal for factory automation cameras and embedded vision system applications. |
| |
Download Datasheet
Product Details | |
|
|
|
|
|
| InGaAs SWIR Sensor for Industrial NIR Imaging & Agricultural Applications | |
SWIR Sensor
from New Imaging Technologies
|
| The NSC1601 from New Imaging Technologies is an InGaAs SWIR Sensor that has a resolution of 640 (H) x 512 (V) pixels. It has a global shutter in a 1" optical format that delivers a frame rate of up to 220 fps (full resolution). This VGA SWIR sensor is ideal for industrial NIR imaging, pharmaceutical food, welding laser instrument, agricultural, and process control surveillance applications. |
| |
Download Datasheet
Product Details | |
|
|
|
| Single Channel Pyroelectric Detector for Fluid Analysis Applications | |
Pyroelectric Detector
from Broadcom
|
| The AFBR-S6PY0575 from Broadcom is a Single Channel Pyroelectric Infrared Flame Detector that has a field of view of 100 deg. It has a specific detectivity of 3.5 x 108 cm.sqrt(Hz)/W and responsivity of 150000 V/W. This thin film pyroelectric detector is ideal for NDIR gas detection, flame detection, automotive gas analysis, medical gas analysis, fluid analysis, and miniaturized design applications. |
| |
Download Datasheet
Product Details | |
|
|
|
|
|
|
|
|
|
|
|
|
|
| 908 nm - 1676 nm, NIR Spectrometer for Industrial Processing Applications | |
Spectrometer
from Viavi Solutions Inc.
|
| The MicroNIR 1700 ES from Viavi Solutions Inc. is a Near Infrared (NIR) Spectrometer that operates at a wavelength of 908 nm - 1676 nm. It has a spectral resolution of up to 1.25% of center wavelength and pixel-to -pixel interval of 6.2 nm. This spectrometer has a working distance below 15 mm and is ideal for pharmaceutical, food, feed, agriculture & industrial processing applications. |
| |
Download Datasheet
Product Details | |
|
|
|
| 0.1 THz - 2.5 THz, Terahertz Spectrometers for NDT Applications | |
Spectrometer
from HÜBNER Photonics
|
| The T-SPECTRALYZER F from HÜBNER Photonics is a Spectrometer that operates at a frequency of 0.1 THz - 2.5 THz. It has a resolution of 10 GHz, dynamic range above 54 dB (at 0.5 THz), and standard measurement time of 5 seconds. This spectrometer uses terahertz waves to facilitate non-destructive contact-free analysis of samples and is ideal for THz-time-domain spectroscopy & NDT applications. |
| |
Download Datasheet
Product Details | |
|
