| Featured Products this Week |
|
|
| 355 nm DPSS Nd:YVO4 Laser for Drilling & Cutting Applications | |
Laser
from MKS | Spectra-Physics
|
| The Explorer One HP 355-6 from MKS | Spectra-Physics is a UV & Green Diode Pumped Solid State (DPSS) Nd:YVO4 Laser that operates at a wavelength of 355 nm. It delivers an output power of greater than 6 W and is ideal for LED & OLED manufacturing processes, drilling, cutting of thin foils, thin film scribing & processing, stereolithography, UV titling & LiDAR applications. |
| |
Download Datasheet
Product Details | |
|
|
|
| 405 nm - 2850 nm, Pulsed Nanosecond Laser for LiDAR & Medical Applications | |
Laser
from Quantel laser by LUMIBIRD
|
| The Peacock XT 355 MB - 140 from Quantel laser by LUMIBIRD is a Tunable Pulsed Nanosecond Laser Source that operates at a wavelength of 405 nm - 2850 nm. It has a peak energy of 40 mJ - 45 mJ and pulse duration of up to 5 ns. This laser has a linewidth of less than 4.5 cm-1 and is ideal for medical, photo-acoustic Imaging, range-finding, LiDAR, spectroscopy & biotechnology applications. |
| |
Download Datasheet
Product Details | |
|
|
|
| 1070 nm Fiber Laser for Welding & Cutting Applications | |
Laser
from Coherent Corp.
|
| The ARM FL6 from Coherent Corp. is a Fiber Laser that operates at a wavelength of 1070 nm. It delivers a nominal output power of 6000 W and has a power stability of ± 1%. This laser has a pulse frequency range from continuous wave to 10 kHz and power range of 1% - 100%. It is ideal for high-quality welding of materials like aluminum or copper and cutting applications. |
| |
Download Datasheet
Product Details | |
|
|
|
| 525 nm Fiber-Coupled Green Laser Diode | |
Laser Diode
from Frankfurt Laser Company
|
| The FERT-525-1W-FC105 from FrankFurt Laser Company is a Fiber-Coupled Green Laser Diode that operates at a wavelength of 525 nm. It delivers an output power of 1 W, has a wavelength tolerance of ± 5 nm, and spectral width of 2 nm. This laser diode has a fiber with core diameter of 105 µm and numerical aperture of 0.22. It requires a DC supply voltage of 6 V, threshold current of 0.3 A, and consumes a current of less than 2 A. |
| |
Download Datasheet
Product Details | |
|
|
|
| 808 nm CW Multimode Laser diode | |
Laser Diode
from Sheaumann Laser
|
| The HW-808-015W-4 from Sheaumann Laser is a Continuous Wave (CW) Laser Diode that operates at a wavelength of 808 nm. It delivers an output power of 15 W and has a slope efficiency of 1.1 W/A. This multimode laser diode has a beam divergence of 32 degrees (vertical far-field) and 10 degrees (horizontal far-field) at FWHM. It requires a threshold current of 2.4 A, DC voltage of 2.5 V, and consumes 15.5 A of current. |
| |
Download Datasheet
Product Details | |
|
|
|
| 653 nm Multimode Laser Diode for Sensing & Medical Applications | |
Laser Diode
from TOPTICA EAGLEYARD
|
| The EYP-BAL-0653-01000-1510-CMT02-0000 from TOPTICA EAGLEYARD is a Multimode Laser Diode that operates at a wavelength of 653 nm. It delivers an output power of 1 W and has a spectral width (FWHM) of 2 nm. This broad area laser diode has a wavelength temperature coefficient of 0.3 nm/K and slope efficiency of 0.7 W/A. It is ideal for sensing and medical applications. |
| |
Download Datasheet
Product Details | |
|
|
|
| 1 µm - 25 µm, Infrared Emitter | |
Infrared Emitter
from MKS | Newport
|
| The 6580IR from MKS | Newport is an Infrared Emitter that operates at a wavelength of 1 µm - 25 µm. It has a nominal radiating area of 3.6 mm x 3.6 mm and color temperature of 1100 K - 1150 K. This infrared emitter has a gold-coated off-axis parabolic mirror and an adjustable rear reflector. It has an average lifetime of 5000 hours and dissipates 9 W of power. This infrared emitter requires a DC supply voltage of 5 V and consumes 1.8 A of current. |
| |
Download Datasheet
Product Details | |
|
|
|
|
|
|
|
| Featured Article | | What is Mode Locking in Lasers? | | Mode Locking is a technique to generate ultra-short pulses in the order of picoseconds (10-12) or femtoseconds (10-15). Lasers that generate a train of periodic ultra-short pulses are called mode-locked lasers. Laser light does not have a single, unmixed frequency or wavelength. All lasers emit light over a natural frequency spectrum or bandwidth. Click here to read the full article. | | | |
|
|
| 1560 nm Optical Frequency Comb for Laser Reference Applications | |
Optical Frequency Comb
from TOPTICA Photonics
|
| The DFC CORE + from TOPTICA Photonics is an Optical Frequency Comb that operates at a center wavelength of 1560 nm (extendable to 420 nm - 2000 nm). It delivers an output power above 10 mW and has a bandwidth of over 20 nm. This OFC is ideal for flyer optical clocks, laser reference, high-resolution spectroscopy, dual-comb spectroscopy, and microwave generation applications. |
| |
Download Datasheet
Product Details | |
|
|
|
| 200 nm - 1160 nm, Spectrometer for Low-Light Fluorescence Applications | |
Spectrometer
from Avantes
|
| The AvaSpec-Hero from Avantes is a Spectrometer with a wavelength of 200 nm - 1160 nm. It has a spectral range of 61 nm - 910 nm and grating groove density of 246 lines/mm - 2400 lines/mm. This spectrometer has a resolution of 0.2 nm - 7 nm and dynamic range of 40000. It has a sensitivity of 445000 counts/µW per ms integration time and is ideal low light fluorescence & Raman applications. |
| |
Download Datasheet
Product Details | |
|
