| Featured Products this Week |
|
|
|
|
|
|
|
| 1070 nm Fiber Lasers for Industrial Cutting Applications | |
Laser
from Coherent Corp.
|
| The EDGE FL Cabinet Version Series from Coherent Corp. are Fiber Lasers that operate at a wavelength of 1070 nm. They deliver a nominal output power of 6 kW - 20 kW and have a power stability of ± 1.5%. These lasers have a pulse frequency range from continuous wave to 5 kHz and are ideal for thin & thick sheet cutting & reflective material cutting applications. |
| |
Download Datasheet
Product Details | |
|
|
|
|
|
|
|
|
|
|
|
|
|
| 1030 nm Yb Femtosecond Laser for Microscopy Applications | |
Laser
from Cycle GmbH
|
| The SONATA from Cycle GmbH is a Yb Femtosecond Laser that operates at a wavelength of 1030 nm. It delivers an output power of 10 mW (fiber output) & 100 mW (free-space output) and has a spectral bandwidth above 14 nm. This laser is ideal for ultrafast pump-probe experiments with synchronization, ASOPS setups, nonlinear microscopy, and industrial ultrafast applications. |
| |
Download Datasheet
Product Details | |
|
|
|
| 1300 nm Infrared SWIR LED for Gas & Proximity Sensing Applications | |
LED
from EPIGAP OSA Photonics GmbH
|
| The OIS-150 1300N-X-T from EPIGAP OSA Photonics GmbH is an SWIR LED with a wavelength of 1300 nm. It has an FWHM of 75 nm and a radiant intensity of 2.5 mW/sr. This LED has a forward voltage of 1.05 V and reverse current of up to 10 μA. It has a glass laminated epoxy circuit substrate with a face-up taping and is ideal for gas sensing & proximity sensing applications. |
| |
Download Datasheet
Product Details | |
|
|
|
| 830 nm CW Superluminescent Diode | |
Superluminescent Diode
from LD4B
|
| The SLD4B-830-2 from LD4B is a Superluminescent Diode that has a mean wavelength of 830 nm. It delivers an output power above 2 mW and has a spectral width of 10 nm. This SLD has a spectral modulation of 1 %, polarization extinction ratio of greater than 13 dB, and wavelength-temperature coefficient of 0.28 nm/oC. It requires a DC supply voltage of 1.8 V and has a built-in monitor photodiode (PD) with a monitor current of 0.15 mA. |
| |
Download Datasheet
Product Details | |
|
|
|
| 800 nm Interference Bandpass Filter for Imaging Applications | |
Optical Filter
from Knight Optical (UK) Ltd
|
| The 800DIR50 from Knight Optical (UK) Ltd is an Interference Bandpass Filter with a wavelength of 800 nm. It has a diameter of 50 mm and thickness of 6.1 mm. This optical filter has a center wavelength (CWL) tolerance of ± 20% (FWHM) and a half bandwidth (HBW) tolerance of ± 20% (FWHM). It is ideal for ANPR imaging, CCTV, and high-end surveillance system applications. |
| |
Download Datasheet
Product Details | |
|
|
| Featured Article | | What is Entanglement Swapping? | | Photonic entanglement swapping is a quantum mechanical process where photons become entangled without direct interaction. Serving as a pivotal experiment in quantum mechanics, entanglement swapping plays a crucial role in the development of quantum networks by harnessing quantum bits, or qubits, for data transmission. Click here to read the full article. | | | |
|
|
| 600 nm - 900 nm, MgO:LiNbO3 Electro-Optic Phase Modulator | |
Electro-Optic Phase Modulator
from Thorlabs Inc
|
| The EO-PM-NR-C1 from Thorlabs Inc is a Magnesium Oxide-Doped Lithium Niobate Electro-Optic Phase Modulator with a wavelength of 600 nm - 900 nm. It has a clear aperture of 2 mm and an input impedance (resonant) of 50 ohms. This EO phase modulator has a halfwave voltage of 135 V (non-resonant) & 10 V (resonant) at 633 nm and an input capacitance (non-resonant) of 14 pF. |
| |
Download Datasheet
Product Details | |
|
|
|
| 200 nm - 800 nm, Spectrometer for Quality Control & Testing Applications | |
Spectrometer
from OZ Optics Ltd.
|
| The DTS0193 from OZ Optics Ltd. is a Spectrometer that operates at a wavelength of 200 nm - 800 nm. It has an optical resolution of 1 nm (FWHM) and integration time of 4 ms - 10 s. This spectrometer has a dark noise of less than 25 counts (at 4 ms exposure) and signal to noise ratio greater than 3000:1. It is ideal for full spectrum analysis, quality control for food industry, and farming applications. |
| |
Download Datasheet
Product Details | |
|
