| Top Laser Diodes |
|
|
| 1064 nm Fabry-Perot Laser Diode for Sensing Applications | |
Laser Diode
from TOPTICA EAGLEYARD
|
| The EYP-RWL-1060-00750-4000-FLW01-0006 from TOPTICA EAGLEYARD is a Fabry-Perot Laser Diode that operates at a center wavelength of 1064 nm. It delivers a minimum output power of 650 mW and has a spectral width (FWHM) of 0.3 nm. This single mode laser diode has a transverse electric (TE) polarization and cavity length of 4400 μm. It is ideal for sensing applications. |
| |
Download Datasheet
Product Details | |
|
|
|
| 440 nm - 460 nm, Fiber Coupled Laser Diode | |
Laser Diode
from PhotonTec Berlin
|
| The M450±10-200-F200/22-V5W-AP from PhotonTec Berlin is a Fiber Coupled Laser Diode that operates at a wavelength of 440 nm - 460 nm. It delivers an output power of 200 W and has a spectral width (FWHM) of 6 nm. This laser diode has a beam parameter product (BPP) of 18 mm.mrad and maximum slope efficiency of 18.9 W/A. It has an optical fiber with a numerical aperture of 0.22 and length of up to 5 m. |
| |
Download Datasheet
Product Details | |
|
|
|
|
|
|
|
|
| 980 nm Fiber-Coupled Laser Diode | |
Laser Diode
from Frankfurt Laser Company
|
| The FRLD-980-3W-FC200-8Pin from Frankfurt Laser Company is a Fiber-Coupled Laser Diode that operates at a central wavelength of 980 nm. It delivers an output power of 3 W and has a spectral width (FWHM) of 6 nm. This laser diode has a temperature drift of 0.3 nm/°C, slope efficiency of 0.9 W/A, and thermistor resistance of 10 ± 5% kΩ. It supports fiber with a diameter of 200 μm (core) & 220 μm (cladding) and numerical aperture of 0.22. |
| |
Download Datasheet
Product Details | |
|
|
|
|
|
|
|
| Sponsored by PhotonTec Berlin | | | |
|
|
| 905 nm Pulsed Laser Diode for LiDAR & Medical Applications | |
Laser Diode
from Laser Components
|
| The 905D1S3JT03SMD from Laser Components is a Pulsed Laser Diode that operates at a wavelength of 905 nm. It delivers an output power of 120 W and has a wavelength temperature coefficient of 0.28 nm/°C. This multi-junction laser diode has a polarization ratio above 98 % and pulse duration of 150 ns. It is ideal for LiDAR, range finding, obstacle detection & medical applications. |
| |
Download Datasheet
Product Details | |
|
|
|
| 660 nm Continuous Wave Fabry-Perot Laser Diode | |
Laser Diode
from LD4B
|
| The LD4B-660-FP-100 from LD4B is a Continuous Wave Fabry-Perot Laser Diode that operates at a wavelength of 660 nm. It delivers an output power of 90 mW & 110 mW and has a spectral width of 1 nm. This fiber-coupled laser diode has a slope efficiency of 0.6 mW/mA and polarization extinction ratio above 17. It requires a threshold current of 60 mA and DC supply voltage of 2.8 V. This laser diode has a built-in monitor photodiode. |
| |
Download Datasheet
Product Details | |
|
|
|
| 750 nm - 770 nm, Laser Diode for Material Processing Applications | |
Laser Diode
from Monocrom
|
| The CS-Mount λ750-770 nm from Monocrom is a Laser Diode that operates at a wavelength of 750 nm - 770 nm. It delivers an output power of up to 40 W (CW) & 200 W (QCW) and has a wavelength tolerance of ± 20 nm. This conduction-cooled laser diode has a spectral width (FWHM) of less than 5 nm and is ideal for material processing, ophthalmology, hair removal, and printing applications. |
| |
Download Datasheet
Product Details | |
|
|
|
| 1271 nm - 1331 nm, CW Laser Diode for Silicon Photonics Applications | |
Laser Diode
from Sumitomo Electric Device Innovations
|
| The STA5602 from Sumitomo Electric Device Innovations is a Continuous Wave Laser Diode that operates at a wavelength of 1271 nm - 1331 nm. It delivers an output power of 70 mW and has a relative intensity noise of -145 dB/Hz. This laser diode is available in a chip package and is ideal as light source for external modulator & silicon photonics applications. |
| |
Download Datasheet
Product Details | |
|
|
|
| 970 nm - 983 nm, Free Space Laser Diode | |
Laser Diode
from AixiZ Service & International
|
| The AH980-601230 from AixiZ Service & International is a Free Space Laser Diode that operates at a wavelength of 970 nm - 983 nm. It delivers an output power of 60 mW and has a threshold current of 15 mA. This laser diode has an internal automatic current control driver and adjustable focusing lens. It has a laser diode reverse voltage 2 V and photodiode reverse voltage of 30 V. This laser diode requires a DC supply voltage of 1.5 V and consumes 95 mA of current. |
| |
Download Datasheet
Product Details | |
|
