| New Photonics Products this Week |
|
|
| Opto-Mechanical Software for Optimization of illumination and Optical Systems | |
Optical Design Software
from Lambda Research Corporation
|
| The TracePro from Lambda Research Corporation is an Opto-Mechanical Software that facilitates the design, analysis, and optimization of optical & illumination systems. It uses a CAD-based interface, interactive layout & optimization tools, and is ideal for a wide range of applications, including lightpipe design, displays, solar collectors, daylighting, biomedical optics, and UV sterilization. |
| |
Download Datasheet
Product Details | |
|
|
|
|
|
|
|
|
| 450 nm Fiber-Coupled Laser Diode | |
Laser Diode
from PhotonTec Berlin
|
| The M450±10-5-F105/22-C1S-P from PhotonTec Berlin is a Laser Diode that operates at a wavelength of 450 nm. It delivers an output power of 5 W and has a spectral width below 10 nm (FWHM). This laser diode has a slope efficiency of 1.72 W/mA and power conversion efficiency of 38%. It has a fiber pigtailed core diameter of 105 &mum and numerical aperture of 0.22. This laser diode supports an SMA fiber connector with fiber lengths of 1 m and 5 m. |
| |
Download Datasheet
Product Details | |
|
|
|
| 760.9 nm DFB Laser Diode for Spectroscopy Applications | |
Laser Diode
from TOPTICA EAGLEYARD
|
| The mini DFB series from TOPTICA EAGLEYARD is a Single Frequency Distributed Feedback (DFB) Laser Diode that operates at a center wavelength of 760.9 nm. It delivers an output power of 12 mW and has a linewidth (FWHM) of 2 MHz. This continuous wave laser diode has a slope efficiency of 0.1 mW/mA and is ideal for spectroscopy, metrology & oxygen detection applications. |
| |
Download Datasheet
Product Details | |
|
|
|
| UV Fused Silica Laser Mirror for Yb:YAG I Harmonic Generation | |
Optical Mirror
from OPTOMAN
|
| The PP-UVFS-25.4-6.35-LLM134 from OPTOMAN is an Ultrafast Laser Mirror with a wavelength of 1030 nm (near total reflection) and 630 nm - 660 nm (partial reflectivity). It has a diameter of 25.4 mm and thickness of 6.35 mm. This UV-grade fused silica mirror has a minimum clear aperture of 20 mm and surface quality of 10-5 S-D (scratch-dig). It is ideal for Yb:YAG I harmonic generation. |
| |
Download Datasheet
Product Details | |
|
|
|
| 1525 nm - 1565 nm, Single-Frequency Laser for Research Applications | |
Laser
from LD-PD Inc
|
| The PL-NLWM-1550-B-2-PA-C-M from LD-PD Inc. is a Narrow Linewidth Single-Frequency Laser Module that operates at a wavelength of 1525 nm - 1565 nm & 1617 nm (ITU grid). It delivers output powers of 10 mW, 30 mW & 60 mW and is ideal for LiDAR, fiber optical hydrophones, resonant fiber optic gyro, distributed fiber sensing, coherent communication & scientific research applications. |
| |
Download Datasheet
Product Details | |
|
|
|
| 520 nm Green Line Laser for Machine Vision Applications | |
Laser
from IMM Photonics GmbH
|
| The IMM1255-520-50-L from IMM Photonics GmbH is a Green Line Laser that operates at a wavelength of 520 nm. It delivers an output power of 50 mW and has a linewidth of 10 nm. This single homogeneous laser produces a beam of diameter 0.7 mm x 100 mm and has a beam divergence of 2.5 mrad - 10 mrad. It is ideal for measuring systems and machine vision applications. |
| |
Download Datasheet
Product Details | |
|
|
|
| 1 A - 40 A, Laser Diode Driver for Industrial Applications | |
Laser Diode Driver
from PicoLAS GmbH
|
| The LDP-CW 40-05 from PicoLAS GmbH is a Laser Diode Driver that delivers an output current of 1 A - 40 A. It has a compliance voltage of less than 5 V and ripple frequency of over 200 kHz. This LDD has a maximum ripple current of 400 mA and analog modulation of 16 kHz. It has a current settling time below 60 μs and is ideal for laser soldering & welding applications. |
| |
Download Datasheet
Product Details | |
|
|
|
| 0.3 Megapixel CMOS Camera for Industrial Applications | |
Scientific & Industrial Camera
from LUCID Vision Labs
|
| The TRT003S-EC from LUCID Vision Labs is a 0.3 MP CMOS Camera with a resolution of 640 (H) x 512 (V) pixels. It has a 1/4.5" optical format and pixel size of 4.86 µm (H) x 4.86 µm (V). This camera uses IMX637, an event-based vision CMOS image sensor that generates event-based data triggered only by changes in scene brightness. It is ideal for demanding industrial environment applications. |
| |
Download Datasheet
Product Details | |
|
|
|
|
|
|
|
| Sponsored by Toptica Eagleyard | | EASY PLUG & SOLUTIONS | | Visit TOPTICA EAGLEYARD’s booth #4713 at SPIE Photonic’s West and learn more about their convenient plug & play options with the fiber-coupled miniECL, DFBs and the miniECL. You can reduce your set-up complexity dramatically. Click here to learn more. | | | |
|
|
| 629 nm Fluorescence Emission Filter for Microscopy Applications | |
Optical Filter
from MKS | Newport
|
| The OD8-EM629-52-B from MKS | Newport is a Fluorescence Emission Filter that operates at a center wavelength of 629 nm. It has a cone half-angle below 7 deg and diameter of Ø25.0 mm with a tolerance of +0.0 mm/-0.1 mm. This optical filter is ideal for fluorescence microscopy & imaging, high throughput screening, medical diagnostics, and analytical instruments applications. |
| |
Download Datasheet
Product Details | |
|
|
|
| 546.1 nm BK7 Plano Convex Spherical Lens | |
Optical Lens
from Union Optic Inc.
|
| The PCX0806 from Union Optic Inc. is a BK7 Plano Convex Spherical Lens that operates at a wavelength of 546.1 nm. It has a diameter of 25.4 mm, diameter tolerance of +0/-0.1 mm, and an edge thickness of 2 mm. This optical lens has a center thickness of 4.1 mm and center thickness tolerance of ± 0.1 mm. It has a focal length of 75 mm and focal length tolerance of ± 2%. This optical lens has a radius of 38.87 mm and surface quality of 60/40 scratch-dig. |
| |
Download Datasheet
Product Details | |
|
|
|
| 8.4 Megapixel IR Corrected Board Lens | |
Optical Lens
from Computar Optics Group
|
| The E1722KRY from Computar Optics Group is an 8.4 Megapixel Optical Lens that has a focal length of 1.7 mm. It has an effective lens aperture of Ø 21.4 mm (front) & Ø 6.3 mm (rear) and a maximum aperture ratio of 1:2.2 (F2.2). This fisheye lens has a back focal length of 3.83 mm (in air) and supports an image format of up to Ø 7.07 mm. It features stereographic projection and is available in a package that measures Ø 25 mm x 23.46 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| 633 nm Optical Mirror for Laser Systems | |
Optical Mirror
from Esco Optics, Inc
|
| The D405633-0 from Esco Optics, Inc. is an Optical Mirror that operates at a wavelength of 633 nm. It has a diameter of 12.7 mm & 25.4 mm and thickness of 3.2 mm. This optical mirror has an angle of incidence of 0 degrees or 45 degrees and surface quality of 40-20 scratch-dig. It has a ground rear surface, and fine-ground, beveled edges for improved durability. This optical mirror is made from Borofloat glass and has dimensions of +/- 0.5 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| Sapphire Window for Optical Measurement Systems | |
Optical Window
from Dayoptics, Inc
|
| The WIN0304 from Dayoptics, Inc. is a Sapphire Window that has a diameter of 10 mm. It has a diameter tolerance of +0.0/-0.2 mm and clear aperture above 85%. This window has a thickness of 1 mm and thickness tolerance of ± 0.2 mm. It has a parallelism of 1 inch and surface quality of 60/40 scratch-dig. This window has a wavefront distortion of lambda (at 633 nm) and protective chamfer that measures 0.25 mm x 45 degrees. |
| |
Download Datasheet
Product Details | |
|
|
|
| 300 nm - 2700 nm, UV-Grade Fused Silica Polarizer | |
Polarizer
from Meadowlark Optics, Inc.
|
| The GPM-150-UNC from Meadowlark Optics, Inc. is a Polarizer with a wavelength of 300 nm - 2700 nm. It has a diameter of 25.4 mm and thickness of 0.087 inch. This UVFS polarizer has a clear aperture of 32 mm and surface quality of 80-50 scratch-dig. It has an acceptance angle of ± 40 deg and a contrast ratio of up to 1000000:1. This polarizer is available in a thin & compact package that measures 05 inch - 4 inch with a mounting thickness of 0.182 inch. |
| |
Download Datasheet
Product Details | |
|
|
|
|
|
|
|
|
|
|
|
|
|
| White Light Interferometer for Thickness Measurement Applications | |
Interferometer
from Micro-Epsilon
|
| The IMS5200-TH26 from Micro-Epsilon is a White Light Interferometer that has a resolution of less than 1 nm. It has a linearity below ± 100 nm and continuously adjustable measuring rate from 100 Hz to 24 kHz. This interferometer employs an internal white LED light source and measures a single transparent layer. It is ideal for industrial inline thickness measurement applications. |
| |
Download Datasheet
Product Details | |
|
|
|
| 532 nm - 732 nm, Spectrometer for Raman Spectroscopy Applications | |
Spectrometer
from Ibsen Photonics
|
| The EAGLE Raman HR 532 from Ibsen Photonics is a Spectrometer that has a spectral range of 532 nm - 732 nm. It has a resolution of 5.8 cm-1 (20 x 1000 μm slit), 9.1 cm-1 (50 x 1000 μm slit), 7.8 cm-1 (20 x 3000 μm slit), & 10.8 cm-1 (50 x 3000 μm slit) and grating efficiency above 90%. This diode array-based spectrometer is ideal for Raman spectroscopy applications. |
| |
Download Datasheet
Product Details | |
|
