| New Photonics Products this Week |
|
|
| Opto-Mechanical Software for Optimization of illumination and Optical Systems | |
Optical Design Software
from Lambda Research Corporation
|
| The TracePro from Lambda Research Corporation is an Opto-Mechanical Software that facilitates the design, analysis, and optimization of optical & illumination systems. It uses a CAD-based interface, interactive layout & optimization tools, and is ideal for a wide range of applications, including lightpipe design, displays, solar collectors, daylighting, biomedical optics, and UV sterilization. |
| |
Download Datasheet
Product Details | |
|
|
|
|
|
|
|
|
| 450 nm Fiber Coupled Laser Diode | |
Laser Diode
from PhotonTec Berlin
|
| The M450±10-100-F100/22-V5W-AP from PhotonTec Berlin is a Laser Diode with a wavelength of 450 nm. It delivers an output power of 100 W and has a spectral width (FWHM) of 6 nm. This laser diode has a beam parameter product (BPP) of 10 mm.mrad and slope efficiency of 21.5 W/A. It supports an SMA905 connector and has a thermistor resistance of 10 kOhms. This laser diode has a threshold current of 0.6 A and power conversion efficiency of 34%. |
| |
Download Datasheet
Product Details | |
|
|
|
| 760 nm DFB Laser Diode for Metrology Applications | |
Laser Diode
from TOPTICA EAGLEYARD
|
| The mini DFB series from TOPTICA EAGLEYARD is a Single Frequency Distributed Feedback (DFB) Laser Diode that operates at a center wavelength of 760 nm. It delivers an output power of 4 mW - 12 mW and has a linewidth (FWHM) of 1 MHz. This continuous wave laser diode has a monitor detector responsivity of 2 μA/mW - 800 μA/mW and slope efficiency of 0.1 mW/mA. It is ideal for Yb spectroscopy and metrology applications. |
| |
Download Datasheet
Product Details | |
|
|
|
| UV Fused Silica Laser Mirror for Yb:YAG I Harmonic Generation | |
Optical Mirror
from OPTOMAN
|
| The PP-UVFS-25.4-6.35-LLM134 from OPTOMAN is a Laser Mirror that operates at a wavelength of 1030 nm (near total reflection) and 630 nm - 660 nm (partial reflectivity). It has a diameter of 25.4 mm and thickness of 6.35 mm. This UV-grade fused silica mirror has a minimum clear aperture of 20 mm and surface quality of 10-5 S-D (scratch-dig). It is ideal for Yb:YAG I harmonic generation. |
| |
Download Datasheet
Product Details | |
|
|
|
| 405 nm - 450 nm, Blue Laser for Machine Vision Applications | |
Laser
from IMM Photonics GmbH
|
| The DOE LASER BLUE from IMM Photonics GmbH is a Blue Laser that operates at a wavelength of 405 nm - 450 nm. It delivers a maximum output power of 80 mW (at 405 nm) & 50 mW (at 450 nm) and has a linewidth of 0.2 mm ± 0.1 mm (at 300 mm). This laser has a beam adjustment focus distance of 300 mm and is ideal for machine vision & measuring systems applications. |
| |
Download Datasheet
Product Details | |
|
|
|
| 75 A Laser Diode Driver for LiDAR Applications | |
Laser Diode Driver
from PicoLAS
|
| The LDP-V 75-200 from PicoLAS GmbH is a Laser Diode Driver that delivers an output current of up to 75 A. It has a pulse duration of 4 ns - 1 µs and rise time of 2.5 ns. This LDD has a compliance voltage of less than 190 V and repetition rate from single shot to 250 kHz. It has a monitor current of 20 A/V and resistance of 50 Ohms. This LDD is ideal for LiDAR, measurements, ignition, range-finding, and biochemistry applications. |
| |
Download Datasheet
Product Details | |
|
|
|
| 405 nm Single-Photon Source for Industrial Applications | |
Single-Photon Source
from AusOptic
|
| The QBTK001 from AusOptic is a Single-Photon Source that operates at a wavelength of 405 nm. It delivers an output power of 15 mW and has a source brightness above 10000 photon pairs/mW/s. This entangled photon source is ideal for polarization dependent loss measurements, polarization state scrambling, academic, research & development, industrial & quantum applications. |
| |
Download Datasheet
Product Details | |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| Silicon Nitride Infrared Emitter | |
Infrared Emitter
from Boston Electronics
|
| The IR-Si295 from Boston Electronics is a Silicon Nitride Infrared Emitter that has a lifetime of 5000 hours. It delivers an output power of 40 W and has an emitter temperature of 1250 °C. This infrared emitter has an active area of 3.5 mm (D) x 12 mm (L) and emissivity of 80%. It requires a DC supply voltage of 12 V and consumes 4.7 A of current. This infrared emitter has elliptical or parabolic reflectors and an optional window. |
| |
Download Datasheet
Product Details | |
|
|
|
| Optical Lens for Inspection Applications | |
Optical Lens
from Computar Optics Group
|
| The M7538-MPX from Computar Optics Group is an Optical Lens that has a focal length of 75 mm. It has an aperture range of F3.8 - F16 (Iris) with a maximum aperture ratio of 1:3.8 and focusing distance from 0.25 m to infinity. This machine vision lens has a back focal length of 11.9 mm and flange back length of 17.53 mm. It has a C mount (M30.5 x P0.5) and is ideal for type 16 megapixel cameras and harsh inspection environment applications. |
| |
Download Datasheet
Product Details | |
|
|
|
|
|
|
|
|
|
|
|
|
|
| 343/515/1030 nm Optical Frequency Converter for Industrial Applications | |
Optical Frequency Converter
from Light Conversion
|
| The CARBIDE HG | 30W UV from Light Conversion is an Optical Frequency Converter that operates at a wavelength of 343 nm, 515 nm, and 1030 nm. It delivers an output power of 30 W and has a pump pulse energy of 80 μJ - 400 μJ. This optical frequency converter has a beam quality factor (M²) of 1.3 and pulse duration of 500 fs. It is ideal for industrial applications. |
| |
Download Datasheet
Product Details | |
|
|
|
| 450 nm - 2000 nm, Cavity-Ringdown Reflectometer for Loss Measurements | |
Reflectometer
from UltraFast Innovations
|
| The GLACIER®-C from UltraFast Innovations is a Cavity-Ringdown Reflectometer that operates at a wavelength of 450 nm - 2000 nm. It has angles of incidence of 5 deg - 45 deg & 0 deg and optics sizes of 0.5 inch, 1 inch, or 2 inch (on request). This s- or p-polarized reflectometer is ideal for coating loss measurement and characterization of highly reflective mirrors. |
| |
Download Datasheet
Product Details | |
|
|
|
| 8 Megapixel CMOS Camera for Imaging Applications | |
Scientific & Industrial Camera
from Canon Medical Systems USA
|
| The IK-4K from Canon Medical Systems USA is an 8 Megapixel CMOS Camera that has a resolution of 1920 (H) x 1080 (V) pixels. It has an electronic shutter in a 1/2.9" optical format and a sensitivity of F5.6 (at 59.94 Hz) & F6.1 (at 50 Hz). This camera has a minimum illumination of 19.5 lux (at 59.94 Hz) and 16.2 lux (at 50 Hz) at F2.2. It is ideal as a component of scientific imaging, life sciences, defense, and live event broadcasting systems. |
| |
Download Datasheet
Product Details | |
|
|
|
| VIS-SWIR Camera for Defense & Surveillance Applications | |
Scientific & Industrial Camera
from Emberion
|
| The Emberion VS20 Compact from Emberion is a 0.33 MP VIS-SWIR Camera that has an active resolution of 640 (H) x 512 (V) pixels. It has a spectral range of 400 nm - 2000 nm and global & built-in electronic shutter that delivers a frame rate of up to 400 fps (at full VGA). This camera is ideal for semiconductor imaging, defense & surveillance, and counterfeit security applications. |
| |
Download Datasheet
Product Details | |
|
|
|
|
|
|
|
|
| 190 nm - 435 nm, Spectrometer for OEM Applications | |
Spectrometer
from Ibsen Photonics
|
| The FSU-305 from Ibsen Photonics is a Spectrometer that operates at a wavelength of 190 nm - 435 nm. It has a resolution of 1 nm and slit widths of 12.5 μm, 35 μm, 50 μm, 70 μm & 125 μm. This spectrometer has a slit height of 250 μm and numerical aperture of 0.16. It has a stray light below 0.03% and temperature-induced shift of less than 0.02 nm/oC. This spectrometer features a unique mirror grating design and is ideal for OEM applications. |
| |
Download Datasheet
Product Details | |
|
