| New Photonics Products this Week |
|
|
|
|
|
|
|
| 450 nm Fiber-Coupled Laser Diode | |
Laser Diode
from PhotonTec Berlin
|
| The M450±10-5-F105/22-C1S-P from PhotonTec Berlin is a Laser Diode with a wavelength of 450 nm. It delivers an output power of 5 W and has a spectral width below 10 nm (FWHM). This laser diode has a slope efficiency of 1.72 W/mA and power conversion efficiency of 38%. It has a fiber pigtailed core diameter of 105 μm and numerical aperture of 0.22. This laser diode supports an SMA fiber connector with fiber lengths of 1 m and 5 m. |
| |
Download Datasheet
Product Details | |
|
|
|
|
|
|
|
|
|
|
|
|
|
| 266 nm DPSS Laser for Raman Spectroscopy Applications | |
Laser
from CryLaS GmbH
|
| The FQCW 266-300 from CryLaS GmbH is a Diode Pumped Solid State Laser that operates at a wavelength of 266 nm. It delivers an output power of 300 mW and has a wavelength stability of ± 0.05 nm. This continuous wave laseris ideal for lithography, Raman spectroscopy & microscopy, wafer inspection, UV optics testing & alignment, and writing of fiber Bragg grating applications. |
| |
Download Datasheet
Product Details | |
|
|
|
| 760 nm - 1470 nm, Diode Lasers for Material Processing Applications | |
Laser
from Lumics
|
| The LuOcean P2 Series from Lumics are Diode Lasers that operate at wavelengths of 760 nm, 785 nm, 808 nm, 890 nm, 940 nm, 975 nm, 1064 nm, and 1470 nm. They deliver an output power of up to 270 W and have a fiber core diameter of 200 µm, 400 µm, or 600 µm with a numerical aperture (NA) of 0.22. These single-wavelength lasers are ideal for material processing applications. |
| |
Download Datasheet
Product Details | |
|
|
|
| 266 nm - 1930 nm, Cloud-Powered Laser for Metrology Applications | |
Laser
from Modulight, Inc.
|
| The ML6600 from Modulight, Inc. is a Cloud-Powered Laser Solution Platform with a wavelength of 266 nm - 1930 nm. It allows multiple lasers of different wavelengths or just one wavelength and can host different laser technologies such as diode, fiber, DPSS, etc. This laser is ideal for flow cytometry, semiconductor metrology, quantum computing, diagnostics, and genetic applications. |
| |
Download Datasheet
Product Details | |
|
|
|
| 9.3/10.6 µm CO2 Lasers for Industrial Applications | |
Laser
from Kern Technologies
|
| The KT200 from Kern Technologies are CO2 Lasers that operate at wavelengths of 9.3 µm and 10.6 µm. They deliver a peak output power of over 200 W and peak power above 400 W with a power stability of ± 5%. These internally collimated lasers have a pulse length of less than 3.75 ms and maximum pulse energy of 750 mJ. They are ideal for industrial applications such as wood engraving, plastic processing, and steel cutting. |
| |
Download Datasheet
Product Details | |
|
|
|
| 1064 nm IR Microchip Laser for Raman Spectroscopy Applications | |
Laser
from Teem Photonics
|
| The STP-100F-1x0 from Teem Photonics is an Infrared Microchip Laser that operates at a wavelength of 1064 nm. It delivers a peak power of 1 kW and has an output energy of 0.75 μJ. This linearly polarised laser is ideal for ranging, differential absorption LiDAR, super-continuum generation, distributed temperature sensing, Raman spectroscopy, and protein cross-linking applications. |
| |
Download Datasheet
Product Details | |
|
|
|
|
|
|
|
|
|
|
| Opto-Mechanical Software for Optimization of illumination and Optical Systems | |
Optical Design Software
from Lambda Research Corporation
|
| The TracePro from Lambda Research Corporation is an Opto-Mechanical Software that facilitates the design, analysis, and optimization of optical & illumination systems. It uses a CAD-based interface, interactive layout & optimization tools, and is ideal for a wide range of applications, including lightpipe design, displays, solar collectors, daylighting, biomedical optics, and UV sterilization. |
| |
Download Datasheet
Product Details | |
|
|
|
|
|
|
|
|
| InGaAs SWIR Sensor for Imaging and Surveillance Applications | |
SWIR Sensor
from New Imaging Technologies
|
| The NSC1601 from New Imaging Technologies is an InGaAs SWIR Sensor that has a resolution of 640 (H) x 512 (V) pixels. It has a global shutter in a 1" optical format that delivers a frame rate of up to 220 fps (full resolution). This VGA SWIR sensor is ideal for industrial NIR imaging, pharmaceutical food, welding laser instrument, semiconductor inspection, and agricultural applications. |
| |
Download Datasheet
Product Details | |
|
|
|
| 500 nm - 2000 nm, Femtosecond Laser Pulse Picker | |
Pulse Picker
from EKSMA Optics
|
| The UP2-KTP-5.5 from EKSMA Optics is a Femtosecond Laser Pulse Picker that operates at a wavelength of 500 nm - 2000 nm. It delivers an average power of 2 W and has a maximum laser repetition rate of 100 MHz (for single pulse picking). This water-cooled pulse picker has an HV pulse duration of up to 5000 ns, and HV pulse rise & fall time below 7 ns. It has an operating rate of up to 1 MHz (driver) and a clear aperture of Ø5.5 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
| 430 nm - 670 nm, TeO2 Acousto-Optic Tunable Filter | |
Acousto-Optic Tunable Filter
from G&H
|
| The AOTF 2885-02 from G&H is a TeO2 Acousto-Optic Tunable Filter that operates at a wavelength of 430 nm - 670 nm. It has an active aperture of 2.5 mm and acoustic velocity of 0.68 mm/µs. This vertically or horizontally polarised AOTF has an RF frequency range of 80 MHz - 152 MHz and RF bandpass (FWHM) of 560 kHz (476 nm). It uses patented side lobe suppression technology to achieve excellent out-of-band suppression. |
| |
Download Datasheet
Product Details | |
|
|
|
| 1310 nm - 1550 nm, Fiber Optic Cable for Underground Duct Installation | |
Fiber Optic Cable
from Corning Incorporated
|
| The 002EU4-T4700D20 from Corning Incorporated is a Single-mode Fiber Optic Cable with wavelengths of 1310 nm, 1383 nm, or 1550 nm. It has a maximum attenuation of 0.35 dB/km and 0.25 dB/km. This round fiber optic cable features an all-dielectric gel-free loose tube design and is ideal for campus backbone applications such as lashed aerial & underground duct installation. |
| |
Download Datasheet
Product Details | |
|
|
|
| Optical Modulator Driver for Military & Space Applications | |
Optical Modulator Driver
from Analog Devices
|
| The HMC870 from Analog Devices is an Optical Modulator Driver that operates from DC to 20 GHz. It has a gain of 17.5 dB (1 GHz - 8 GHz), 16.5 dB (8 GHz - 16 GHz) & 16 dB (16 GHz - 20 GHz) and small signal bandwidth of 20 GHz. This optical modulator driver is ideal for 10 Gbps NRZ MZ & low-Vπ modulator driving, 10 Gbps RZ transmission, and military & space applications. |
| |
Download Datasheet
Product Details | |
|
|
|
| Closed-Cycle Optical Cryostat for Research Applications | |
Optical Cryostat
from Bluefors
|
| The 4K Cryostat from Bluefors is a Closed-Cycle Optical Cryostat that has a cooling capacity above 0.5 W (at 4.2 K). It has a base temperature of up to 3.2 K and cooldown time of 4 hours. This optical cryostat features a sleeve and helium reservoir design to provide contact-free refrigeration. It has a temperature stability of ± 5 mK and is ideal for scientific research & low-vibration applications. |
| |
Download Datasheet
Product Details | |
|
|
|
| 190 nm - 850 nm, Spectrometer for OEM Applications | |
Spectrometer
from Spectrum Scientific, Inc
|
| The UV-470 OEM from Spectrum Scientific, Inc is a Spectrometer that has a spectral range of 190 nm - 850 nm. It has a resolution of 1.4 nm (190 nm - 850 nm) and focal number of 2. This spectrometer has a pixel size of 8 μm x 200 μm and pixel well depth of 100000 e-. It has a signal-to-noise ratio of 1200:1 and an integration time of 0.1 ms - 6.5 s. This spectrometer has a dynamic range of 2000:1 and is ideal for OEM applications. |
| |
Download Datasheet
Product Details | |
|
|
|
|
|
|
