| Featured Products this Week |
|
|
|
|
|
|
|
| 450 nm Fiber-Coupled Laser Diode | |
Laser Diode
from PhotonTec Berlin
|
| The M450±10-50-F100/22-B50-AP from PhotonTec Berlin is a Laser Diode that operates at a wavelength of 450 nm. It delivers an output power of 50 W and has a spectral width of 6 nm (FWHM). This laser diode has a slope efficiency of 21.5 W/mA and power conversion efficiency of 34%. It has a fiber pigtailed core diameter of 100 μm, cladding diameter of 500 μm, and numerical aperture of 0.22. This fiber-coupled laser diode supports an SMA 905 fiber connector. |
| |
Download Datasheet
Product Details | |
|
|
|
| 1310 nm DFB Laser Diodes for Analog Communication Applications | |
Laser Diode
from Modulight, Inc.
|
| The ML1010 series from Modulight, Inc. are DFB Laser Diodes that operate at a wavelength of 1310 nm. They deliver an output power of 3 mW and have a -20 dB spectral width of up to 1 nm. These laser didoes have a slope efficiency of 0.09 W/A - 0.15 W/A & above 0.05 W/A. They are ideal for communications such as HFC, RF-over-fibre, wireless repeaters & analogue, and defense applications. |
| |
Download Datasheet
Product Details | |
|
|
|
| 785 nm Laser Diode for Medical & Military Applications | |
Laser Diode
from RPMC Lasers Inc.
|
| The LDX-3520-785-FC from RPMC Lasers is a Laser Diode that operates at a wavelength of 785 nm. It delivers an output power of 5000 mW and has a spectral width of 2 nm. This laser diode has a slope efficiency of 1.20 W/A and an aperture size of 200 μm. It has beam divergence (FWHM) of 26 deg (fast axis) & 7 deg (slow axis) and expected lifetime above 10,000 hours. This laser diode is ideal for medical, industrial, research, and military applications. |
| |
Download Datasheet
Product Details | |
|
|
|
| Multi-Channel Pyroelectric Detector for Flame Detection Applications | |
Pyroelectric Detector
from InfraTec
|
| The LRM-292 from InfraTec GmbH Infrarotsensorik und Messtechnik is a Multi-Channel Pyroelectric Detector that has a minimum field of view of 60 deg. It has a detectivity of 3 x 108 cm·sqrt(Hz)/W and maximum rms noise density of 45 µV/sqrt(Hz). This lithium tantalate pyroelectric detector operates in current mode and has a thermal time constant of 75 ms. It is ideal for gas analysis & flame detection applications. |
| |
Download Datasheet
Product Details | |
|
|
|
| 780 nm Semiconductor Optical Amplifier for OCT Applications | |
Optical Amplifier
from Innolume
|
| The SOA0770016YY30DB from Innolume is a SOA that operates at a wavelength of 780 nm. It delivers an output power of 10 mW and has a bandwidth (FWHM) of 13 nm. This fiber-coupled optical amplifier has a gain bandwidth of 16 nm and small signal gain of 30 dB (at 300 mA). It is ideal for optical preamplifiers, OCT, external cavity lasers, and active media for tunable lasers & swept source applications. |
| |
Download Datasheet
Product Details | |
|
|
|
|
|
|
|
|
| 340 nm - 540 nm, Optical Frequency Converter for Spectroscopy Applications | |
Optical Frequency Converter
from Radiantis
|
| The Oria Blue from Radiantis is a Femtosecond and Picosecond SHG Optical Frequency Converter that converts the IR Ti:Sapphire wavelengths, across 680 nm - 1080 nm (9259 cm-1 - 14705 cm-1), into the UV, across 340 nm - 550 nm (18181 cm-1 - 29411 cm-1). It is ideal for linear & non-linear spectroscopy, plasmonics, pump-probe spectroscopy, Raman spectroscopy & microscopy applications. |
| |
Download Datasheet
Product Details | |
|
|
|
|
|
|
|
|
|
|
| 190 nm - 850 nm, Spectrometer for OEM Applications | |
Spectrometer
from Spectrum Scientific, Inc
|
| The UV-470 OEM from Spectrum Scientific, Inc is a Spectrometer that has a spectral range of 190 nm - 850 nm. It has a resolution of 1.4 nm (190 nm - 850 nm) and focal number of 2. This spectrometer has a pixel size of 8 μm x 200 μm and pixel well depth of 100000 e-. It has a signal-to-noise ratio of 1200:1 and an integration time of 0.1 ms - 6.5 s. This spectrometer has a stray light of less than 0.07% (340 nm) & 0.01% (435 nm) and is ideal for OEM applications. |
| |
Download Datasheet
Product Details | |
|
