| New Photonics Products this Week |
|
|
| 350 nm - 2400 nm, Supercontinuum Source for OCT Applications | |
Supercontinuum Source
from Leukos
|
| The DISCO UV from Leukos is a Supercontinuum Source that has a spectral bandwidth of 350 nm - 2400 nm. It delivers a total average power of over 10 mW and has a repetition rate of 2 kHz. This unpolarised supercontinuum source is ideal for pump/probe spectroscopy, flow cytometry, optical coherence tomography (OCT), microscopy, and optical component characterisation applications. |
| |
Download Datasheet
Product Details | |
|
|
|
|
|
|
|
|
| 670 nm Superluminescent Diode Module for OCT Applications | |
Superluminescent Diode
from Superlum
|
| The S670.7.15 from Superlum is a Superluminescent Diode (SLD) Module with a central wavelength of 670 nm. It delivers an output power of up to 15 mW and has a spectrum width (FWHM) of 7 nm. This module has a secondary coherence subpeaks of -25 dB and is ideal for optical coherence tomography, low coherence measurements, spectroscopy & low speckle illumination applications. |
| |
Download Datasheet
Product Details | |
|
|
|
| 405 nm LED Chip on Board Module for Integration Applications | |
LED
from Violumas
|
| The VC1X1C45L6-405 from Violumas is a UVA LED Chip on Board (COB) Module that operates at a peak wavelength of 405 nm. It has a wavelength accuracy of ± 5 nm and full width at half magnitude (FWHM) of 12 nm. This LED has a radiant flux of 1285 mW and radiant angle of 60 degrees. It is solder-free and is ideal for easy testing, wiring & integration applications. |
| |
Download Datasheet
Product Details | |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| 355 nm Variable Beam Expander for R&D Applications | |
Beam Expander
from Edmund Optics
|
| The 87-566 from Edmund Optics is a Variable Beam Expander that operates at a wavelength of 260 nm - 365 nm. It has a design wavelength of 355 nm and an expansion power of 2X - 8X. This research-grade beam expander has an aperture size of 15 mm (entrance) & 30 mm (exit) and a transmission of over 95%. It uses a fused silica substrate and is ideal for high-power laser applications such as prototyping and R&D. |
| |
Download Datasheet
Product Details | |
|
|
|
| Achromatic Galilean Beam Expander for Mid-IR Applications | |
Beam Expander
from Thorlabs Inc
|
| The GBE02-B from Thorlabs Inc is a Fixed Beam Expander that has an expansion of 2X. It has a broadband anti-reflection coating range of 650 nm - 1050 nm with a transmission of above 96% (780 nm & 980 nm). This achromatic Galilean beam expander has a maximum input beam diameter of 9.7 mm and 8.5 mm (diffraction-limited). It is ideal for narrowband and mid-IR applications. |
| |
Download Datasheet
Product Details | |
|
|
|
|
|
|
|
|
|
|
| 363 nm - 420 nm, Spatial Light Modulator for Hyperspectral Imaging | |
Spatial Light Modulator
from Texas Instruments
|
| The DLP9500UV from Texas Instruments is a Spatial Light Modulator that operates at a wavelength of 363 nm - 420 nm. It has a display resolution of 1920 x 1080 pixels and is ideal for direct imaging lithography, laser marking & repair systems, computer to plate printers, rapid prototype machines, 3D printers, ophthalmology, photo-therapy & hyperspectral imaging applications. |
| |
Download Datasheet
Product Details | |
|
|
|
| 400 nm - 1100 nm, DKDP Pockels Cell for Q-Switching Applications | |
Pockels Cell
from Shandong Laserton Optic Co., Ltd.
|
| The D-Q12A from Shandong Laserton Optic Co., Ltd. is a Deuterated Potassium Dihydrogen Phosphate (DKDP) Pockels Cell that operates at a wavelength of 400 nm - 1100 nm. It has a clear aperture of 12 mm and an insertion loss below 2%. This pockels cell is ideal for pulsed laser system, medical laser system, aesthetic laser system, and Q-switching applications. |
| |
Download Datasheet
Product Details | |
|
|
|
|
|
|
|
|
|
|
|
|
|
| 0.1 GHz - 6 GHz, Optical Delay Line for Radar Calibration Testing | |
Optical Delay Line
from RFOptic
|
| The Altimeter Optical Delay Line from RFOptic is an Optical Delay Line that has a frequency of 0.1 GHz - 6 GHz. It has number of altitudes from 1 to 224 steps with a minimum step size of 0.5 ft. This optical delay line has an altitude range of 1 ft - 100000 ft and selectable altitude segments of 1 ft, 2 ft, 4 ft (custom). It is ideal for radar calibration testing and altimeter applications. |
| |
Download Datasheet
Product Details | |
|
|
|
| 200 nm - 50 µm, Czerny Turner Monochromator | |
Monochromator
from Bentham Instruments
|
| The DTMc300 from Bentham Instruments is a Czerny Turner Monochromator with a spectral range of 200 nm - 50 μm. It has a linear dispersion of 1.35 nm/mm and wavelength accuracy of ± 0.1 nm. This double monochromator has a wavelength reproducibility of ± 0.025 nm and wavelength acquisition speed of 2000 nm/s. It has a stray light rejection of 10-8 (at 2.5 FWHM) and focal length of 600 mm (total) & 300 mm (individual unit). |
| |
Download Datasheet
Product Details | |
|
|
|
| 120 deg Borescope for Endoscopy & Military Applications | |
Borescope
from viZaar
|
| The PROBE 6.4 from viZaar is a Borescope with a field of view above 120 deg. It has a diameter of 6.4 mm and depth of field (DOF) of 8 mm - 80 mm. This borescope has a screen size of 5&Prime, direction of view of 0 deg or 90 deg, and resolution of 1200 x 720 pixels. It uses a 1/6" CMOS image sensor with total pixels of 1 million and is ideal for inspection & military applications. |
| |
Download Datasheet
Product Details | |
|
|
|
| 5 Megapixel Color CMOS Camera | |
Scientific & Industrial Camera
from Sugitoh
|
| The BFS-U3-50S5C-C from Sugitoh is a 5 Megapixel Color CMOS Camera that has a resolution of 2448 (H) x 2048 (V) pixels. It has a 2/3" optical format that delivers a maximum frame rate of 35 fps and has a pixel size of 3.45 μm x 3.45 μm. This camera integrates a Sony IMX264 image sensor and features a C-mount interface for lens. It can be controlled via a USB interface and is available in a package that measures 29 mm x 29 mm x 30 mm. |
| |
Download Datasheet
Product Details | |
|
|
|
|
|
|
|
|
| FTIR Spectrometer for Material Research & Industrial Applications | |
Spectrometer
from Bruker
|
| The INVENIO from Bruker is a Fourier Transform Infrared (FTIR) Spectrometer that has a spectral range of 8000 cm-1 - 340 cm-1 (basic) and 28000 cm-1 - 15 cm-1 (top-end). It has a signal-to-noise ratio of 60000:1 and peak-to-peak value of 4 cm-1. This spectrometer is ideal for analytical service, pharma, polymer, industrial, academia, material research, and life science applications. |
| |
Download Datasheet
Product Details | |
|
