| Featured Products this Week |
|
|
| 532 nm DPSS Q-Switched Laser for Material Processing Applications | |
Laser
from Unilase Ltd
|
| The UL532HRR from Unilase Ltd is a DPSS Q-Switched Laser that operates at a wavelength of 532 nm. It delivers an average output power of 25 W and has a pulse energy of 50 µJ. This Nd:YVO4 green laser has TEM00 mode with a beam quality factor (M2) of 1.3 and polarisation ratio above 100:1. It has a pulse duration of up to 15 ns and is ideal for high throughput materials processing applications. |
| |
Download Datasheet
Product Details | |
|
|
|
| 550 nm - 750 nm, Continuous Wave Tunable Dye Ring Laser | |
Laser
from Sirah Lasertechnik
|
| The Matisse 2 DX from Sirah Lasertechnik is a Continuous Wave Dye Ring Laser that operates at a wavelength of 550 nm - 750 nm. It delivers an output power of up to 5.5 W and has a linewidth of less than 100 kHz rms/100 msec & 70 kHz rms/100 µsec. This horizontally polarized tunable laser produces a beam of radius 0.6 mm - 0.7 mm and has a beam divergence of less than 1.2 mrad (half-angle). |
| |
Download Datasheet
Product Details | |
|
|
|
| 975 nm Unmounted Diode Laser Bar for Direct-Diode Applications | |
Laser Diode
from Coherent Corp.
|
| The 150W 30FFx4 mm from Coherent Corp. is a Diode Laser Bar that operates at a central wavelength of 975 nm. It delivers an output power of 150 W and has a wavelength accuracy of ± 10 nm. This TE-polarized diode laser bar has a spectral width below 10 nm (at FWHM) and fill factor of 30 %. It has a beam divergence of 31 degrees and is ideal for pumping and direct-diode applications. |
| |
Download Datasheet
Product Details | |
|
|
|
| CMOS Image Sensor for Smart Homes & Mobile Phone Applications | |
CMOS Image Sensor
from Pixart
|
| The PAC7640LT from Pixart is a CMOS Image Sensor that has a resolution of 400 (H) x 400 (V) pixels. It has a global shutter that delivers a maximum frame rate of 120 fps. This image sensor has a pixel size of 3 µm x 3 µm, dynamic range of 51.4 dB, and signal-to-noise ratio of 38 dB. It is ideal for smart homes, offices & classrooms appliances & mobile phone applications. |
| |
Download Datasheet
Product Details | |
|
|
|
|
|
|
|
|
| 1300 nm Edge-Emitting LED for Data Transmission Systems | |
LED
from OSI Laser Diode, Inc.
|
| The LDT 362 from OSI Laser Diode, Inc. is an Edge-Emitting LED that operates at a center wavelength of 1300 nm. It has a spectral width of 80 nm and minimum output power of 40 µW & 80 µW. This multimode fiber LED has a spectrum vs. temperature coefficient of 0.75 nm/°C and is ideal for data transmission systems, fiber optic modems & TFOCA systems applications. |
| |
Download Datasheet
Product Details | |
|
|
|
|
|
|
|
|
| 1064 nm Fiber-Coupled Acousto Optic Modulator | |
Acousto-Optic Modulator
from BeamQ Lasers
|
| The Fiber-Coupled 100MHz AOM from BeamQ Lasers is an Acoustic-Optic Modulator that operates at a wavelength of 1064 nm. It delivers a continuous wave optical output power of 5 W and has an operating wavelength range of ± 5 nm. This AOM has a driving power of 2 W and peak output power of 10 kW. It has a maximum working frequency of 200 MHz and an insertion loss of 0.6 dB. This AOM has a minimum isolation and return loss of 50 dB. |
| |
Download Datasheet
Product Details | |
|
|
| Sponsored by EMC Directory | | |
|
|
| 1000 cm^-1 - 4300 cm^-1, SFG Vibrational Spectrometer | |
Spectrometer
from EKSPLA
|
| The SFG Classic from Ekspla is a Sum Frequency Generation (SFG) Vibrational Spectrometer that has a spectral range from 1000 to 4300 cm-1. It has a spectral resolution of up to 6 cm-1 and visible beam wavelength of 532 nm & an optional wavelength of 1064 nm. This spectrometer is ideal for the studies of surface structure, remote sensing, surface dynamics, and environmental problems. |
| |
Download Datasheet
Product Details | |
|
|
|
| 532 nm - 700 nm, VIS Spectrometer for Chemical & Biological Research | |
Spectrometer
from CNI Laser
|
| The RPB-532 from CNI Laser is a Raman spectrometer that operates at a wavelength of 532 nm - 700 nm. It has a broad spectral range from 200 to 4500 cm-1 with an optical resolution of 8 - 12 cm-1 and wavelength accuracy of ± 0.5 nm. This spectrometer is ideal for Raman spectral analysis, food safety testing, medical diagnosis, geological exploration, and hazard detection applications. |
| |
Download Datasheet
Product Details | |
|
