| Featured Products this Week |
|
|
| 355 nm UV Picosecond Laser for Drilling & Marking Applications | |
Laser
from MKS | Spectra-Physics
|
| The IceFyre UV30 from Spectra- Physics is a UV Picosecond Laser that operates at a wavelength of 355 nm. It delivers an output power of greater than 30 W and has a maximum pulse energy above 60 μJ (at 500 kHz). This laser is ideal for spectroscopy, fluorescence microscope, time resolved measurement, interferometry, flow cytometry, and biomedical microscopy applications. |
| |
Download Datasheet
Product Details | |
|
|
|
| 561 nm Visible Laser Module for Biomedical Microscopy Applications | |
Laser
from QD Laser
|
| The QLD0593-6120 from QD Laser is a Visible Laser Module that operates at a wavelength of 561 nm. It delivers an output power of 20 mW and has a beam divergence (FWHM) of 5 deg (parallel) & 10 deg (perpendicular). This laser has a beam quality factor (M2) of 1.2 and is ideal for spectroscopy, fluorescence microscope, time resolved measurement & interferometry applications. |
| |
Download Datasheet
Product Details | |
|
|
|
| 520 nm Green Line Laser for Machine Vision Applications | |
Laser
from IMM Photonics GmbH
|
| The IMM1255-520-50-L from IMM Photonics GmbH is a Green Line Laser that operates at a wavelength of 520 nm. It delivers an output power of 50 mW and has a linewidth of 10 nm. This single homogeneous laser produces a beam of diameter 0.7 mm x 100 mm and has a beam divergence of 2.5 mrad - 10 mrad. It is ideal for measuring systems & machine vision applications. |
| |
Download Datasheet
Product Details | |
|
|
|
| 1534 nm DPSS Lasers for LiDAR & Instrumentation Applications | |
Laser
from RPMC Lasers Inc.
|
| The KAUKAS SERIES from RPMC Lasers Inc. are Diode Pumped Solid State (DPSS) Lasers that operate at a wavelength of 1534 nm. They have a pulse width of less than 11 ns and pulse energy of up to 3 mJ. These nanosecond pulsed lasers are ideal for LiDAR, laser ranging, Laser-Induced Breakdown Spectroscopy (LIBS), metrology, and instrumentation applications. |
| |
Download Datasheet
Product Details | |
|
|
|
| 980 nm Fiber-Coupled Laser Diode | |
Laser Diode
from Frankfurt Laser Company
|
| The FRLD-980-3W-FC200-8Pin from Frankfurt Laser Company is a Fiber-Coupled Laser Diode that operates at a central wavelength of 980 nm. It delivers an output power of 3 W and has a spectral width (FWHM) of 6 nm. This laser diode has a temperature drift of 0.3 nm/°C, slope efficiency of 0.9 W/A, and thermistor resistance of 10 ± 5% kΩ. It supports fiber with a diameter of 200 μm (core) & 220 μm (cladding) and numerical aperture of 0.22. |
| |
Download Datasheet
Product Details | |
|
|
|
| 400 nm - 1100 nm, Silicon Photodiode for Light Sensing Applications | |
Photodiode
from EPIGAP OSA Photonics GmbH
|
| The EOPD-940-0-15 from EPIGAP OSA Photonics GmbH is a Silicon Photodiode that has a spectral range of 400 nm - 1100 nm. It has a peak sensitivity wavelength of 940 nm and responsivity of 0.22 A/W (at 410 nm) & 0.6 A/W (940 nm). This photodiode is ideal for light sensing and detection in medical devices, industrial monitoring & scientific instrumentation applications. |
| |
Download Datasheet
Product Details | |
|
|
|
| 670 nm - 855 nm, Photodetector for Offset Phase Locking Applications | |
Photodetector
from Vescent
|
| The D2-260 from Vescent is a Photodetector that operates at a wavelength of 670 nm - 855 nm. It has a bandwidth from 250 MHz to above 9 GHz and maximum input optical power of 1 mW. This pre-amplified detector converts an oscillating optical signal (a beat note) into electrical high/low signal. It is ideal for detecting beat notes or offset phase locking and pulse timing & trigger generation applications. |
| |
Download Datasheet
Product Details | |
|
|
|
| USB Laser Power Meter for Real-Time Measurements | |
Laser Power Meter
from Edmund Optics
|
| The 89-307 from Edmund Optics is a USB Laser Power Meter that has a power range of 3 μW - 30 kW and 1 pW - 3 W. It has a monitor accuracy of ± 0.5% and real time data transfer rate of 10 Hz. This laser power meter has two types of detectors: thermopiles & photodetectors. It provides multiple real-time statistical functions such as current value, maximum, minimum, average, standard deviation, RMS & PTP stability & time and is ideal for real time measurements. |
| |
Download Datasheet
Product Details | |
|
|
|
|
|
| 375 nm - 1550 nm, Cavity-Ringdown Reflectometer for Loss Measurements | |
Reflectometer
from UltraFast Innovations
|
| The GLACIER from UltraFast Innovations is a Cavity-Ringdown Reflectometer that operates at a wavelength of 375 nm - 1550 nm. It has an angle of incidence of 5 deg - 45 deg & 0 deg and optics size of 0.5 inch, 1 inch, 2 inch. This s Or p polarized reflectometer has the capability to measure reflectivities and is ideal for coating loss measurement & characterization of highly reflective mirrors. |
| |
Download Datasheet
Product Details | |
|
|
|
| 532 nm - 732 nm, Spectrometer for Raman Spectroscopy Applications | |
Spectrometer
from Ibsen Photonics
|
| The EAGLE Raman HR 532 from Ibsen Photonics is a Spectrometer that has a spectral range of 532 nm - 732 nm. It has a resolution of 5.8 cm-1 (20 x 1000 μm slit), 9.1 cm-1 (50 x 1000 μm slit), 7.8 cm-1 (20 x 3000 μm slit), & 10.8 cm-1 (50 x 3000 μm slit) and grating efficiency above 90%. This diode array-based spectrometer has a numerical aperture of 0.2 and is ideal for Raman spectroscopy applications. |
| |
Download Datasheet
Product Details | |
|
