AIX-904-25

Request Quote

Note: Your Quotation Request will be directed to AixiZ Service & International.

The AIX-904-25 from AixiZ Service & International is a Laser Diode with Wavelength 885 nm, 905 nm, 915 nm, Output Power 25 mW, Output Power 25 mW, Threshold Current 12 to 25 mA, Operating Current 35 to 60 mA. More details for AIX-904-25 can be seen below.

Product Specifications

View similar products

Product Details

  • Part Number
    AIX-904-25
  • Manufacturer
    AixiZ Service & International
  • Description
    885 to 915 nm Laser Diodes with 25 mW Power

General Parameters

  • Type
    Free Space Laser Diode
  • Operation Mode
    CW Laser
  • Wavelength
    885 nm, 905 nm, 915 nm
  • Output Power
    25 mW
  • Output Power
    25 mW
  • Slope Efficiency
    0.3 to 0.7 mW/mA
  • Beam Divergence Parallel
    7 to 15 Degree
  • Beam Divergence Perpendicular
    28 to 38 Degree
  • Threshold Current :
    12 to 25 mA
  • Operating Current
    35 to 60 mA
  • Operating Current
    35 to 60 mA
  • Operating Voltage
    1.5 to 2.3 V
  • Monitor Current
    0.1 to 0.6 mA
  • Package Type
    Module
  • Package
    Module
Click to view more product details on manufacturer's website
