AF4B125ED75L

Laser Diode by Anritsu Corporation
Download Datasheet
Request Quote

Note: Your Quotation Request will be directed to Anritsu Corporation.

The AF4B125ED75L from Anritsu Corporation is a Laser Diode with Wavelength 1460 to 1490 nm, Output Power 0.25 W, Output Power (CW) 0.25 W, Threshold Current 70 to 150 mA, Operating Voltage 2 V. More details for AF4B125ED75L can be seen below.

Product Specifications

View similar products

Product Details

  • Part Number
    AF4B125ED75L
  • Manufacturer
    Anritsu Corporation

General Parameters

  • Type
    Fiber-Coupled Laser Diode
  • Operation Mode
    CW Laser
  • Wavelength
    1460 to 1490 nm
  • Output Power
    0.25 W
  • Output Power (CW)
    0.25 W
  • Spectral Width (FWHM)
    5 to 10 nm
  • Wavelength Tolerance
    ±15 nm
  • Threshold Current :
    70 to 150 mA
  • Reverse Voltage(PD)
    10 V
  • Operating Voltage
    2 V
  • Monitor Current
    100 to 1000 uA
  • Fiber Modes
    Single Mode, Polarization Maintaining
  • Polarization
    17 dB
  • Photo Diode Dark Current
    0.1 uA
  • Package Type
    Butterfly
  • Package
    14-Pin
  • Note
    Dark Current: 0.1 uA

Temperature

  • Operating Temperature
    -20 to 70 Degree C
  • Storage Temperature
    -40 to 85 Degree C
