K878BAHRN-30.00W

Laser Diode by BWT BEIJING
Download Datasheet
Request Quote

Note: Your Quotation Request will be directed to BWT BEIJING.

The K878BAHRN-30.00W from BWT BEIJING is a Laser Diode with Wavelength 878.6 nm (Center), Output Power 30 W, Output Power 30 W, Output Power (CW) 30 W, Threshold Current 1.5 A. More details for K878BAHRN-30.00W can be seen below.

Product Specifications

View similar products

Product Details

  • Part Number
    K878BAHRN-30.00W
  • Manufacturer
    BWT BEIJING
  • Description
    878.6nm, 30W Wavelength-Stabilized Fiber Coupled Diode Laser

Applications

  • Application
    Solid-state laser pumping

General Parameters

  • Type
    Fiber-Coupled Laser Diode
  • Operation Mode
    CW Laser
  • Wavelength
    878.6 nm (Center)
  • Output Power
    30 W
  • Output Power
    30 W
  • Output Power (CW)
    30 W
  • Spectral Width (FWHM)
    0.5 nm
  • Slope Efficiency
    2.7 W/A
  • Wavelength Tolerance
    ±1 nm
  • Wavelength Temp. Coefficient
    0.03 nm/Degree C
  • Threshold Current :
    1.5 A
  • Operating Current
    12.5 to 13 A
  • Operating Current
    12.5 to 13 A
  • Operating Voltage
    5 to 6 V
  • Numerical Aperture
    0.22
  • Lead Soldering Temperature
    260 Degree C
  • Package Type
    Fiber Pigtailed
  • Package
    4-Pin, Fiber Pigtailed
  • Relative Humidity
    15 to 75% RH

Physical Properties

  • Fiber core diameter
    200 µm
  • Fiber length
    1.5 m

Connections & Interface

  • Connector
    SMA905

Temperature

  • Operating Temperature
    20 to 30 Degree C
  • Storage Temperature
    -20 to 70 Degree C
