40W 20FFx1mm

Laser Diode by Coherent Corp.
Download Datasheet
Request Quote

Note: Your Quotation Request will be directed to Coherent Corp..

The 40W 20FFx1mm from Coherent Corp. is a Laser Diode with Wavelength 1060 nm, Output Power 40 W, Output Power 40 W, Threshold Current 2 to 4 A, Operating Current 49 A. More details for 40W 20FFx1mm can be seen below.

Product Specifications

View similar products

Product Details

  • Part Number
    40W 20FFx1mm
  • Manufacturer
    Coherent Corp.
  • Description
    Unmounted Diode Laser Bars (UMBs), 1060 nm

Applications

  • Application
    Medical, Aesthetics, Illumination, Materials Processing

General Parameters

  • Type
    Free Space Laser Diode
  • Wavelength
    1060 nm
  • Output Power
    40 W
  • Output Power
    40 W
  • Configuration
    Multi-Emitter, Single Bar
  • Beam Divergence Parallel
    7 Degree
  • Beam Divergence Perpendicular
    30 to 35 Degree
  • Wavelength Tolerance
    ±20 nm
  • Emitter Width
    100 µm
  • Transverse Mode
    TE
  • Wavelength Temp. Coefficient
    0.4 nm/Degree C
  • Threshold Current :
    2 to 4 A
  • Operating Current
    49 A
  • Operating Current
    49 A
  • Operating Voltage
    1.7 V
  • Cooling Method
    Conduction-Cooled
  • Number of Emitters
    19
  • Package Type
    Bar
  • Stack/Array
    Single Bar
