I0785SB0050B-IS

Download Datasheet
Request Quote

Note: Your Quotation Request will be directed to Innovative Photonic Solutions.

The I0785SB0050B-IS from Innovative Photonic Solutions is a Laser Diode with Wavelength 785 nm, Output Power 50 mW, Output Power 50 mW, Operating Current 200 mA, Operating Current 200 mA. More details for I0785SB0050B-IS can be seen below.

Product Specifications

View similar products

Product Details

  • Part Number
    I0785SB0050B-IS
  • Manufacturer
    Innovative Photonic Solutions
  • Description
    50 mW, Laser Diode with 785 nm wavelength having Butterfly package

Applications

  • Application
    High Resolution Raman Spectroscopy, Direct-Diode Frequency Doubling, Fiber Laser Seeding, Metrology & Interferometry, Remote Sensing
  • Application Industry
    Spectroscopy, Interferometry, Metrology, Seeding, Remote Sensing

General Parameters

  • Type
    Fiber-Coupled Laser Diode
  • Operation Mode
    CW Laser
  • Wavelength
    785 nm
  • Output Power
    50 mW
  • Output Power
    50 mW
  • Spectral Width (FWHM)
    100 kHz
  • Beam Quality Factor (M2)
    <1.2
  • Beam Divergence
    2 mrad
  • Beam Shape
    Elliptical
  • Wavelength Tolerance
    ±0.5 nm
  • Polarization Extinction Ratio
    >17 to 20 dB
  • Transverse Mode
    TEM00
  • Forward Current(PD)
    30 µA
  • Operating Current
    200 mA
  • Operating Current
    200 mA
  • Operating Voltage
    2.5 V
  • Thermistor Resistance
    10 kOhms
  • Laser Class
    Class 3B, Class IV
  • Fiber Modes
    Single Mode
  • Package Type
    Butterfly
  • Package
    14-Pin Butterfly
  • Note
    Stabilized Output Spectrum: <0.007 nm / Degree C), Beam Exit Angle: <1 Degree

Temperature

  • Storage Temperature
    15 to 45 Degree C
