IPFPC1303

Laser Diode by InPhenix
Download Datasheet
Request Quote

Note: Your Quotation Request will be directed to InPhenix.

The IPFPC1303 from InPhenix is a Laser Diode with Wavelength 1290 to 1330 nm, Output Power 10 mW, Output Power 0.01 W, Output Power (CW) 0.01 W, Threshold Current 8 to 12 mA. More details for IPFPC1303 can be seen below.

Product Specifications

View similar products

Product Details

  • Part Number
    IPFPC1303
  • Manufacturer
    InPhenix
  • Description
    Uncooled Fabry-Perot Laser Diode Chips

Applications

  • Application
    Optical Transmission, Data Communication, Local Optical Network, FTTH (Fiber to the Home)

General Parameters

  • Technology
    Fabry-Perot (FP), Multi-Quantum Well (MQW)
  • Type
    Free Space Laser Diode
  • Operation Mode
    CW Laser
  • Wavelength
    1290 to 1330 nm
  • Output Power
    10 mW
  • Output Power
    0.01 W
  • Output Power (CW)
    0.01 W
  • Spectral Width (FWHM)
    1.2 to 2 nm
  • Slope Efficiency
    0.4 mW/mA
  • Beam Divergence Parallel
    20 Degree
  • Beam Divergence Perpendicular
    20 Degree
  • Threshold Current :
    8 to 12 mA
  • Operating Current
    0.035 A
  • Operating Current
    35 mA
  • Operating Voltage
    1.1 to 1.6 V
  • Operating Current (CW)
    0.035 A
  • Package Type
    Chip

Temperature

  • Operating Temperature
    -40 to 85 Degree C
  • Storage Temperature
    -40 to 100 Degree C
