Intense 6120

Laser Diode by Intense Limited
Request Quote

Note: Your Quotation Request will be directed to Intense Limited.

The Intense 6120 from Intense Limited is a Laser Diode with Wavelength 980 nm, Output Power 200 W, Output Power 200 W, Output Power (CW) 200 W, Threshold Current 30 mA. More details for Intense 6120 can be seen below.

Product Specifications

View similar products

Product Details

  • Part Number
    Intense 6120
  • Manufacturer
    Intense Limited
  • Description
    The Intense Series 6100 are very high brightness, 980nm single mode laser diodes with up to 200mW of kink-free power.

Applications

  • Application
    Wafer, Fabrication, Packaging, Production, Test & Characterization, Defence and Security, Medical, Commercial, Industrial
  • Application Industry
    production Process, Market Sectors, Defence and Security, Medical, Commercial, Industrial

General Parameters

  • Type
    Free Space Laser Diode
  • Operation Mode
    CW Laser
  • Wavelength
    980 nm
  • Output Power
    200 W
  • Output Power
    200 W
  • Output Power (CW)
    200 W
  • Spectral Width (FWHM)
    2 nm
  • Slope Efficiency
    0.95 W/A
  • Configuration
    Single-Emitter
  • Beam Divergence
    5 x 25 Degree
  • Wavelength Tolerance
    ±5 nm, ±10 nm
  • Threshold Current :
    30 mA
  • Operating Current
    250 A
  • Operating Current
    250 A
  • Operating Current (CW)
    250 A
  • Fiber Modes
    Single Mode
  • Package Type
    TO-Can
  • Package
    5.6 mm, 9 mm, C Mount
  • Note
    Source Size: 3 µm
