905D5S2L3J08X

Laser Diode by Laser Components

Note: Your Quotation Request will be directed to Laser Components.

The 905D5S2L3J08X from Laser Components is a Laser Diode with Wavelength 895 to 915 nm, Output Power 650 W, Operating Current 60 A, Threshold Current 1500 mA, Output Power (CW) 650 W. More details for 905D5S2L3J08X can be seen below.

Product Specifications View similar products

Product Details

  • Part Number
    905D5S2L3J08X
  • Manufacturer
    Laser Components

Applications

  • Application
    Range Finding, Surveying Equipment, Weapons Simulation, Laser Radar, Ceilometer, Optical Trigger, Medical
  • Application Industry
    Medical

General Parameters

  • Configuration
    Quad stack, Stack
  • Operation Mode
    Pulsed Laser
  • Wavelength
    895 to 915 nm
  • Output Power
    650 W
  • Pulse Duration
    150 ns
  • Spectral Width (FWHM)
    4 nm
  • Operating Current
    60 A
  • Threshold Current
    1500 mA
  • Laser Gain Medium
    InGaAs/GaAs
  • Beam Divergence Parallel
    10 Degree
  • Beam Divergence Perpendicular
    25 Degree
  • Emitting Area
    800 x 440 µm
  • Package Type
    TO-Can
  • Package
    8-32 coax, 9 mm CD, TO-18, 5.6 mm CD
  • Stack/Array
    Quad stack, Stack
  • Type
    Free Space Laser Diode
  • Output Power (CW)
    650 W

Temperature

  • Operating Temperature
    -45 to 85 Degree C
  • Storage Temperature
    -55 to 100 Degree C
