PL-FP-1064-B-A81-PA

Laser Diode by LD-PD Inc
589 more products from this company
Download Datasheet
Request Quote

Note: Your Quotation Request will be directed to LD-PD Inc.

The PL-FP-1064-B-A81-PA from LD-PD Inc is a Laser Diode with Wavelength 1064 nm (Center), Output Power 70 mW, Output Power 70 mW, Threshold Current 20 to 30 mA, Operating Current 200 to 300 mA. More details for PL-FP-1064-B-A81-PA can be seen below.

Product Specifications

View similar products

Product Details

  • Part Number
    PL-FP-1064-B-A81-PA
  • Manufacturer
    LD-PD Inc
  • Description
    1064nm FP PM Module Laser Diodes

Applications

  • Application
    Printing, Optical Data Storage, Spectral Analysis, Graphics, Laser Ranging, Illumination, Defense

General Parameters

  • Technology
    Fabry-Perot (FP)
  • Type
    Fiber-Coupled Laser Diode
  • Operation Mode
    CW Laser
  • Wavelength
    1064 nm (Center)
  • Output Power
    70 mW
  • Output Power
    70 mW
  • Spectral Width (FWHM)
    0.5 nm
  • Wavelength Tolerance
    ±1 nm
  • Polarization Extinction Ratio
    17 to 20 dB nm
  • Wavelength Temp. Coefficient
    -4.4 nm / Degree C
  • Threshold Current :
    20 to 30 mA
  • Forward Voltage
    1.8 to 2.5 V
  • Reverse Voltage
    2 V
  • Operating Current
    200 to 300 mA
  • Operating Current
    200 to 300 mA
  • Reverse Voltage(PD)
    20 V
  • Thermistor Resistance
    9.5 to 10.5 kOhms
  • Fiber Modes
    Polarization Maintaining
  • Photo Diode Dark Current
    0.1 µA
  • Package Type
    Butterfly
  • Package
    14-pin butterfly
  • Note
    Case Temperature: -5 to 70 Degree C

Physical Properties

  • Fiber core diameter
    0.9 mm

Connections & Interface

  • Connector
    FC/APC
