JDL-BAB-75-62-808-TE-300-1.5

Laser Diode by Lumispot Tech
Request Quote

Note: Your Quotation Request will be directed to Lumispot Tech.

The JDL-BAB-75-62-808-TE-300-1.5 from Lumispot Tech is a Laser Diode with Wavelength 805 nm, 808 nm, 811 nm, Output Power 300 W, Output Power 300 W, Threshold Current 22 to 25 A, Operating Current 253 to 275 A. More details for JDL-BAB-75-62-808-TE-300-1.5 can be seen below.

Product Specifications

View similar products

Product Details

  • Part Number
    JDL-BAB-75-62-808-TE-300-1.5
  • Manufacturer
    Lumispot Tech
  • Description
    High-Power Diode Laser Bar | 808 nm, 300 W, QCW

Applications

  • Application
    Pumping Source Systems, Printing
  • Application Industry
    Inudustry, Medical, Defence Research

General Parameters

  • Type
    Free Space Laser Diode
  • Operation Mode
    QCW Laser, Pulsed Laser
  • Wavelength
    805 nm, 808 nm, 811 nm
  • Output Power
    300 W
  • Output Power
    300 W
  • Spectral Width (FWHM)
    3 to 5 nm
  • Pulse Duration
    200 µs
  • Slope Efficiency
    1.2 to 1.3 W/A
  • Configuration
    Bar
  • Beam Divergence
    36 to 68 Degree (Parallel), 8 to 11 Degree (Perpendicular)
  • Beam Divergence Parallel
    36 to 68 Degree
  • Beam Divergence Perpendicular
    8 to 11 Degree
  • Emitter Width
    90 to 110 µm
  • Threshold Current :
    22 to 25 A
  • Operating Current
    253 to 275 A
  • Operating Current
    253 to 275 A
  • Operating Voltage
    2.1 to 2.2 V
  • Series Resistance
    3 mOhms
  • Package Type
    Bar
  • Package
    Bar
  • Note
    Bar width: 9600 to 10000 µm, Cavity length: 1480 to 1520 µm, Thickness: 115 to 125 µm
