2CM-105

Laser Diode by SemiNex Corporation
Download Datasheet
Request Quote

Note: Your Quotation Request will be directed to SemiNex Corporation.

The 2CM-105 from SemiNex Corporation is a Laser Diode with Wavelength 1470 nm(+/-20), Output Power 8 W, Output Power 8 W, Output Power (CW) 8 W, Threshold Current 1 A. More details for 2CM-105 can be seen below.

Product Specifications

View similar products

Product Details

  • Part Number
    2CM-105
  • Manufacturer
    SemiNex Corporation
  • Description
    2 CHIP MODULE FIBER COUPLED LASER DIODE

Applications

  • Application
    Professional Medical, DPSS pump source, LiDAR, Free Space Communications, Military / Aerospace

General Parameters

  • Type
    Fiber-Coupled Laser Diode
  • Operation Mode
    CW Laser
  • Wavelength
    1470 nm(+/-20)
  • Output Power
    8 W
  • Output Power
    8 W
  • Output Power (CW)
    8 W
  • Spectral Width (FWHM)
    10 nm
  • Slope Efficiency
    0.55 W/A
  • Configuration
    Single-Emitter
  • Beam Divergence Parallel
    12 Degree
  • Beam Divergence Perpendicular
    12 Degree
  • Duty Cycle
    100%
  • Emitter Width
    200 µm
  • Wavelength Temp. Coefficient
    0.55 nm/Degree C
  • Power Conversion Efficiency
    20
  • Threshold Current :
    1 A
  • Operating Current
    13.5 A
  • Operating Current
    13.5 A
  • Operating Voltage
    2.9 V
  • Operating Current (CW)
    13.5 A
  • Fiber Modes
    Multi-Mode
  • Number of Emitters
    1
  • Series Resistance
    0.1 Ohms
  • Package Type
    Module

Physical Properties

  • Fiber core diameter
    200 µm
  • Fiber length
    1 Meters
  • Weight
    170 g

Connections & Interface

  • Connector
    SMA905

Temperature

  • Operating Temperature
    10 to 30 °C
  • Storage Temperature
    -20 to 80 °C
