MCM-107

Laser Diode by SemiNex Corporation
Download Datasheet
Request Quote

Note: Your Quotation Request will be directed to SemiNex Corporation.

The MCM-107 from SemiNex Corporation is a Laser Diode with Wavelength 1555 nm(+/-20), Output Power 15 W, Output Power 15 w, Output Power (CW) 15 W, Threshold Current 9 A. More details for MCM-107 can be seen below.

Product Specifications

View similar products

Product Details

  • Part Number
    MCM-107
  • Manufacturer
    SemiNex Corporation
  • Description
    6-CHIP LASER MODULE WITH FIBER BUNDLE

Applications

  • Application
    OEM Medical, DPSS pump source, Free Space Communications, Military / Aerospace, Thermal Processing

General Parameters

  • Type
    Fiber-Coupled Laser Diode
  • Operation Mode
    CW Laser
  • Wavelength
    1555 nm(+/-20)
  • Output Power
    15 W
  • Output Power
    15 w
  • Output Power (CW)
    15 W
  • Spectral Width (FWHM)
    15 nm
  • Slope Efficiency
    1.7 W/A
  • Configuration
    Multi-Emitter
  • Beam Divergence Parallel
    12 Degree
  • Beam Divergence Perpendicular
    12 Degree
  • Duty Cycle
    100%
  • Emitter Width
    375 µm
  • Threshold Current :
    9 A
  • Operating Current
    9 A
  • Operating Current
    9 A
  • Operating Voltage
    9 V
  • Operating Current (CW)
    9 A
  • Fiber Modes
    Multi-Mode
  • Number of Emitters
    6
  • Series Resistance
    0.4 Ohms
  • Package Type
    Module

Physical Properties

  • Fiber core diameter
    375 µm
  • Fiber length
    1.5 Meters
  • Weight
    550 g

Connections & Interface

  • Connector
    SMA905

Temperature

  • Operating Temperature
    10 to 30 °C
  • Storage Temperature
    -20 to 80 °C
