LP-ML1001D-31-FA

Laser Diode by LD-PD Inc
589 more products from this company
Download Datasheet
Request Quote

Note: Your Quotation Request will be directed to LD-PD Inc.

The LP-ML1001D-31-FA from LD-PD Inc is a Laser Diode with Wavelength 1310 nm (Center), Output Power 8 dBm (0.0063 W), Output Power 8 dBm (0.0063 W), Threshold Current 10 mA, Operating Current 55 to 100 mA. More details for LP-ML1001D-31-FA can be seen below.

Product Specifications

View similar products

Product Details

  • Part Number
    LP-ML1001D-31-FA
  • Manufacturer
    LD-PD Inc
  • Description
    20GHz 1310nm DFB laser module

Applications

  • Application
    Antenna Remoting, Cellular and PCS Networks, Military Communications, Tracking, Telemetry, and Control

General Parameters

  • Technology
    Distributed Feedback (DFB)
  • Type
    Fiber-Coupled Laser Diode
  • Operation Mode
    CW Laser
  • Wavelength
    1310 nm (Center)
  • Output Power
    8 dBm (0.0063 W)
  • Output Power
    8 dBm (0.0063 W)
  • Slope Efficiency
    0.2 W/A
  • Modulation Bandwidth
    20 GHz
  • Threshold Current :
    10 mA
  • Forward Current(PD)
    2 mA
  • Peak Forward Current
    120 mA
  • Reverse Voltage
    1 V
  • Operating Current
    55 to 100 mA
  • Operating Current
    55 to 100 mA
  • Reverse Voltage(PD)
    15 V
  • Operating Voltage
    1.5 to 2.5 V
  • Peak Power
    20 dBm (Front)
  • Thermistor Resistance
    10 kOhms
  • Capacitance
    20 pF
  • Monitor Current
    0.05 to 2 mA
  • Photo Diode Dark Current
    50 nA
  • Package Type
    Butterfly
  • Package
    7-pin butterfly
  • Relative Humidity
    0.85
  • Relative Intensity Noise
    -130 to -150 dB/Hz
  • Return Loss
    -10 to -6 dB
  • Note
    Input 1 dB Compression: 18 dBm

Physical Properties

  • Fiber length
    1 m

Connections & Interface

  • Connector
    FC/APC

Temperature

  • Operating Temperature
    -40 to 85 Degree C
  • Storage Temperature
    -40 to 85 Degree C
