NUU205E

Laser Diode by Nichia Corporation
Download Datasheet
Request Quote

Note: Your Quotation Request will be directed to Nichia Corporation.

The NUU205E from Nichia Corporation is a Laser Diode with Wavelength 370 to 380 nm, Output Power 0.15 W, Output Power (CW) 0.15 W, Threshold Current 200 to 260 mA, Operating Current 0.39 A. More details for NUU205E can be seen below.

Product Specifications

View similar products

Product Details

  • Part Number
    NUU205E
  • Manufacturer
    Nichia Corporation
  • Description
    LD Receptacle Module

General Parameters

  • Type
    Free Space Laser Diode
  • Operation Mode
    CW Laser
  • Wavelength
    370 to 380 nm
  • Output Power
    0.15 W
  • Output Power (CW)
    0.15 W
  • Threshold Current :
    200 to 260 mA
  • Operating Current
    0.39 A
  • Operating Voltage
    4.4 V
  • Monitor Current
    1 mA
  • Package Type
    Module
  • Package
    3-Pin

Physical Properties

  • RoHS
    yes
