CVD 165

Laser Diode by OSI Laser Diode, Inc.
Download Datasheet
Request Quote

Note: Your Quotation Request will be directed to OSI Laser Diode, Inc..

The CVD 165 from OSI Laser Diode, Inc. is a Laser Diode with Wavelength 905 nm, Output Power 60 W, Output Power (CW) 60 W, Operating Temperature -40 to 85 Degree C, Storage Temperature -55 to 85 Degree C. More details for CVD 165 can be seen below.

Product Specifications

View similar products

Product Details

  • Part Number
    CVD 165
  • Manufacturer
    OSI Laser Diode, Inc.
  • Description
    905 nm High Power Pulsed Laser Diodes

Applications

  • Application
    Rangfinding/ceilometer, weapons simulation, optical fuses, Serveying equipment

General Parameters

  • Type
    Free Space Laser Diode, Fiber-Coupled Laser Diode
  • Operation Mode
    Pulsed Laser
  • Wavelength
    905 nm
  • Output Power
    60 W
  • Output Power (CW)
    60 W
  • Spectral Width (FWHM)
    5.0 to 12 nm
  • Configuration
    Single-Emitter
  • Peak Power
    60 W
  • Package Type
    TO-Can
  • Package
    5.6 mm, TO18, 9mm, TO5

Temperature

  • Operating Temperature
    -40 to 85 Degree C
  • Storage Temperature
    -55 to 85 Degree C

Technical Documents
Click to view more product details on manufacturer's website
