The LDX-3520-785-FC from RPMC Lasers Inc. is a Laser Diode that operates at a wavelength of 785 nm. It delivers an output power of 5000 mW and has a spectral width of 2 nm. This laser diode has a slope efficiency of 1.20 W/A and an aperture size of 200 μm. It has beam divergence (FWHM) of 26 deg (fast axis) & 7 deg (slow axis) and expected lifetime above 10,000 hours. This transverse electric polarized laser diode has a threshold current of 760 mA and forward voltage 1.9 V. It supports HHL, BTF, and FCP fibers and can be controlled via a 9 mm SMA connector. This laser diode consumes 4925 mA of current and is ideal for medical, industrial, research & military applications.
