MCM-105

Laser Diode by SemiNex Corporation

Note: Your Quotation Request will be directed to SemiNex Corporation.

The MCM-105 from SemiNex Corporation is a Laser Diode with Wavelength 1550 nm(+/-20), Output Power 20 W, Output Power 20 w, Operating Voltage 10.7 V, Operating Current 10.5 A. More details for MCM-105 can be seen below.

Product Specifications View similar products

Product Details

  • Part Number
    MCM-105
  • Manufacturer
    SemiNex Corporation
  • Description
    7-CHIP LASER MODULE WITH FIBER BUNDLE

Applications

  • Application
    OEM Medical, DPSS pump source, Free Space Communications, Military / Aerospace, Thermal Processing

General Parameters

  • Configuration
    Multi-Emitter
  • Operation Mode
    CW Laser
  • Wavelength
    1550 nm(+/-20)
  • Output Power
    20 W
  • Output Power
    20 w
  • Spectral Width (FWHM)
    15 nm
  • Operating Voltage
    10.7 V
  • Operating Current
    10.5 A
  • Duty Cycle
    100%
  • Operating Current
    10.5 A
  • Emitter Width
    375 µm
  • Threshold Current
    0.7 A
  • Beam Divergence Parallel
    12 Degree
  • Beam Divergence Perpendicular
    12 Degree
  • Fiber Modes
    Multi-Mode
  • Number of Emitters
    7
  • Series Resistance
    0.5 Ohms
  • Operating Current (CW)
    10.5 A
  • Slope Efficiency
    2.2 W/A
  • Package Type
    Module
  • Type
    Fiber-Coupled Laser Diode
  • Wavelength Temp. Coefficient
    0.55 nm/Degree C
  • Output Power (CW)
    20 W

Physical Properties

  • Fiber core diameter
    375 µm
  • Fiber length
    1.5 Meters
  • Weight
    570 g

Temperature

  • Operating Temperature
    10 to 30 °C
  • Storage Temperature
    -20 to 80 °C
