The LDX-3105-780-FC from RPMC Lasers Inc. is a Fiber Coupled Laser Diode that operates at a wavelength of 780 nm. It delivers an output power of 1200 mW and has a spectral width of 2 nm. This Transverse Magnetic (TM) polarized laser diode has a slope efficiency of 1.25 W/A and divergence 26 deg (fast axis) & 7 deg (slow axis). It has a threshold current of 270 mA, forward voltage of 1.9 V, and an aperture size of 50 um. This laser diode supports HHL, BTF, and FCP fiber with core diameter of 105 µm, and fiber size of 200 µm. It is compatible with SMA2 connector and has a lifetime above 10000 hours. This laser diode consumes 1235 mA of current and is ideal for medical, industrial, research, and military applications.
